Porsche Cayenne I facelift (2007-2010) right rear lid warning light Wiring diagram
This page shows the only wiring diagram for the component.right rear lid warning light, which is found in the car Porsche Cayenne I facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear lid warning light (1 of 1)
BLU WIRE
BODY ACCELERATION SENSOR
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BUZZER REAR LID
CAN LOW CAN HIGH TERMINAL 30
COMPUTER DATA LINES SYSTEM
FUSE 22
GRN/YEL WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HYDRAULIC PUMP
HYDRAULICS MTR 1
HYDRAULICS MTR 2 TERMINAL 31
INCLINATION SENS GND
LEFT FUSE BOX (UNDER LEFT SIDE OF DASH)
LEFT REAR LID DOOR SURROUND
LEFT REAR LID WARNING LIGHT
ON-BOARD COMPUTER NETWORK CONTROL UNIT (UNDER LEFT SIDE OF DASH)
ORG/BRN WIRE
ORG/GRN WIRE
REAR LID CLOSE SWITCH
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT REAR LID DOOR SURROUND
RIGHT REAR LID WARNING LIGHT
SPARE WHEEL 1
SPARE WHEEL 2
TAILGATE CONTROL UNIT
YEL WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Tailgate & fuel door release circuit (2 of 2) -> RIGHT REAR LID WARNING LIGHT
