Porsche Cayenne I facelift (2007-2010) right passenger side drive motor wiring diagram
This page shows the only wiring diagram for the component.right passenger side drive motor, which is found in the car Porsche Cayenne I facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right passenger side drive motor wiring diagram (1 of 1)
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
FOOTWELL FLAP
FRESH AIR/ CIRCULATING AIR DRIVE MOTOR
FRONT 2 + 2 CLIMATRONIC CONTROL UNIT (IN CENTER CONSOLE)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
GRY/WHT WIRE
LEFT CENTER OUTLET DRIVE MOTOR
LEFT FOOTWELL DRIVE MOTOR
LEFT FOOTWELL OUTPUT SENSOR
LEFT TEMPERATURE DRIVE MOTOR
PASSENGER AIR FLOW
PASSENGER AIR FLOW PASSENGER AIR FLOW
PASSENGER AIR FLOW PASSENGER AIR FLOW FOOTWELL FLAP FOOTWELL FLAP
PNK PASSENGER AIR FLOW WIRE
PNK WIRE
PNK/GRN WIRE
PNK/VIO WIRE
PNK/WHT WIRE
REAR EVAPORATIVE AIR INTAKE TEMPERATURE SENSOR
RED/WHT WIRE
RIGHT CENTER OUTLET DRIVE MOTOR
RIGHT FOOTWELL DRIVE MOTOR
RIGHT FOOTWELL OUTPUT SENSOR
RIGHT OUTPUT SENSOR
RIGHT PASSENGER SIDE DRIVE MOTOR
RIGHT TEMPERATURE DRIVE MOTOR
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
YEL WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Automatic a/c circuit, front & rear a/c (1 of 5) -> RIGHT PASSENGER SIDE DRIVE MOTOR
