Porsche Cayenne I facelift (2007-2010) mirrors system navigation system Wiring diagram
This page shows the only wiring diagram for the component.mirrors system navigation system, which is found in the car Porsche Cayenne I facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirrors system navigation system (1 of 1)
BLK/BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
EC MIRROR EMERGENCY CALL POTI SUPPLY POTI SIGNAL POTI GROUND
FUSE 36
FUSE 42
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN AND START
MIRRORS SYSTEM NAVIGATION SYSTEM
NAVIGATION SYSTEM
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH)
ROOF CONSOLE
TERM 15
VIO/BLU WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Overhead console circuit -> MIRRORS SYSTEM NAVIGATION SYSTEM
