Porsche Cayenne I facelift (2007-2010) left right oxygen oxygen sensor 2 sensor 1 Wiring diagrams
This page contains all the electrical diagrams for the component. left right oxygen oxygen sensor 2 sensor 1, in which he is found in the car Porsche Cayenne I facelift (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left right oxygen oxygen sensor 2 sensor 1 (1 of 2)
3.6L
AKF VALVE
BLK WIRE
BLU/RED WIRE
BRN/GRN WIRE
CLIMATRONIC CONTROL UNIT
COOLING FAN 1
COOLING FAN 2
E-BOX (LEFT SIDE OF WATER BOX)
EXHAUST SHIFT SHAFT VALVE
FROM E-BOX, FUSE 8 (DIAGRAM 2 OF 8)
FUEL VALVE
FUSE 10
FUSE 11
FUSE 12
FUSE 17
FUSE 18
FUSE 7
FUSE 8
FUSE 9
GRN BRN/ WIRE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
INTAKE SHAFT
LEFT GENERATOR RELAY
LEFT OXYGEN SENSOR 2
LEFT RIGHT OXYGEN OXYGEN SENSOR 2 SENSOR 1
MOTOR CONTROL UNIT
OIL LEVEL SENSOR
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT OXYGEN SENSOR 1
SPEED SENSOR
TANK HEATING VENTING ELEMENT VALVE
TANK LEAK SENSOR
TO E-BOX, FUSE 11 (DIAGRAM 2 OF 8)
TO E-BOX, MAIN RELAY 1 (DIAGRAM 3 OF 8)
VACUUM PUMP RELAY
Go to component -> Power distribution circuit (2 of 8) -> LEFT RIGHT OXYGEN OXYGEN SENSOR 2 SENSOR 1
Wiring diagram left right oxygen oxygen sensor 2 sensor 1 (2 of 2)
& RECEIVER
3.6L W/O KZH
BLU/YEL WIRE
BRN WIRE
E BOX HANDY
E-BOX (LEFT SIDE OF WATER BOX)
FROM E-BOX, FUSE 11 (DIAGRAM 3 OF 8)
FROM LEFT FUSE BOX, FUSE 43 (DIAGRAM 5 OF 8)
FROM RIGHT FUSE BOX, FUSE 36 (DIAGRAM 5 OF 8)
FRONT MIDDLE COCKPIT CIGAR LIGHTER PLUG SOCKET
FUSE
FUSE 12 (4.8L TURBO)
FUSE 17
FUSE 18
FUSE FUSE
GRY WIRE
LEFT BOOT PLUG SOCKET
LEFT CIRCULATION PUMP RELAY (3.6L W/O WZH)
LEFT FUSE BOX (UNDER LEFT SIDE OF DASH)
LEFT OXYGEN SENSOR 2
LEFT RIGHT OXYGEN OXYGEN SENSOR 2 SENSOR 1
PARKING HEATER CONTROL UNIT
PASSENGER FOOTWELL PLUG SOCKET 1
PASSENGER FOOTWELL PLUG SOCKET 2
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
REMOTE +
RIGHT BOOT PLUG SOCKET
RIGHT CIRCULATION PUMP RELAY
RIGHT FUSE BOX (UNDER RIGHT SIDE FUSE FUSE OF DASH)
RIGHT OXYGEN SENSOR 1
SUPPORT POSITION RELAY 1
TELEPHONE CONTROL UNIT
TERM 30
TERM 31
TERM 31 LEFT REAR CENTER CONSOLE PLUG SOCKET
TERM 31 RIGHT REAR CENTER CONSOLE PLUG SOCKET
TRAILER CONNECTION DEVICE PARKING ASSIST CONTROL UNIT
YEL/BLU WIRE
Go to component -> Power distribution circuit (8 of 8) -> LEFT RIGHT OXYGEN OXYGEN SENSOR 2 SENSOR 1
