Porsche Cayenne I facelift (2007-2010) left front passenger seat heater footwell potenti- plug socket 1 ometer Wiring diagram
This page shows the only wiring diagram for the component.left front passenger seat heater footwell potenti- plug socket 1 ometer, which is found in the car Porsche Cayenne I facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front passenger seat heater footwell potenti- plug socket 1 ometer (1 of 1)
BLK/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BUTTON PANEL
GRY WIRE
INTERIOR MONITORING DEACTIVATION SWITCH
LEFT FRONT CLS SAFE
LEFT FRONT DOOR EXIT LIGHT
LEFT FRONT DOOR HANDLE LIGHT
LEFT FRONT DOOR PANEL LIGHTS
LEFT FRONT DOOR WARNING LIGHT
LEFT FRONT PASSENGER SEAT HEATER FOOTWELL POTENTI- PLUG SOCKET 1 OMETER
PASSENGER FOOTWELL PLUG SOCKET 2
POWER WINDOWS, DOOR LOCKS SYSTEMS
PSM SWITCH
RED WIRE
RED/GRN WIRE
RIGHT FRONT CENTRAL LOCKING BUTTON
RIGHT FRONT CLS SAFE
RIGHT FRONT DOOR EXIT LIGHT
RIGHT FRONT DOOR HANDLE LIGHT
RIGHT FRONT DOOR PANEL LIGHTS
RIGHT FRONT DOOR WARNING LIGHT
RIGHT FRONT POWER WINDOW SWITCH
RIGHT FRONT SEAT HEATER POTENTIOMETER
RIGHT REAR SEAT HEATER POTENTIOMETER
TAILGATE SWITCH
TERM 31
WHT/VIO WIRE
Go to component -> Interior lights circuit (3 of 5) -> LEFT FRONT PASSENGER SEAT HEATER FOOTWELL POTENTI- PLUG SOCKET 1 OMETER
