Porsche Cayenne I facelift (2007-2010) front pass- right enger's rear side- footwell bolster light heater Wiring diagram
This page shows the only wiring diagram for the component.front pass- right enger's rear side- footwell bolster light heater, which is found in the car Porsche Cayenne I facelift (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front pass- right enger's rear side- footwell bolster light heater (1 of 1)
BLK WIRE
BOSE AUDIO OPTION PACK
BOSE AUDIO OPTION PACK SHIELD
BRN WIRE
CD CHANGER
DVD DRIVE
EXCEPT BASIC TELEPHONE
FRONT PASS- ENGER'S BACKREST SEAT HEATER
FRONT PASS- ENGER'S BACKREST SIDE- BOLSTER HEATER
FRONT PASS- ENGER'S SEAT WELL HEATER
FRONT PASS- RIGHT ENGER'S REAR SIDE- FOOTWELL BOLSTER LIGHT HEATER
INFO-NAVIGATION COMPUTER
INFO-NAVIGATION COMPUTER SHIELD
M/T
METERING PUMP
MICROPHONE ENTRY NOISE SHIELD
NCA WIRE
NEUTRAL POSITION E-BOX SWITCH HANDY
PASS- ENGER'S SEAT MEMORY
PASSENGER SIDE AIRBAG
PCM 2
PDCC CONTROL UNIT
RED WIRE
SATELLITE RECEIVER
SUBWOOFER
TELEPHONE
TELEPHONE PREPARATION
TRANSFER CASE)
TRANSMISSION
TV TUNER
W/ PASSENGER SEAT MEMORY
WABCO HP PLUS RIDE HEIGHT CONTROL COMPRESSOR
WHT WIRE
Go to component -> Ground distribution circuit (4 of 7) -> FRONT PASS- RIGHT ENGER'S REAR SIDE- FOOTWELL BOLSTER LIGHT HEATER
