Porsche Cayenne I facelift (2007-2010) 5 2 4 1 3 6 plus switched signal term 30 signal term 31 Wiring diagrams
This page contains all the electrical diagrams for the component. 5 2 4 1 3 6 plus switched signal term 30 signal term 31, in which he is found in the car Porsche Cayenne I facelift (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 5 2 4 1 3 6 plus switched signal term 30 signal term 31 (1 of 2)
1 2 TERM 30 TERM 31
1 2 VNC + MICROPHONE
4 5 6 7 8 9 10 FR+ DR DEEP RANGE SPKR FL+ DR DEEP RANGE SPKR
5 2 4 1 3 6 PLUS SWITCHED SIGNAL TERM 30 SIGNAL TERM 31
BLK WIRE
BLU WIRE
BOSE AMPLIFIER
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/YEL WIRE
EFFECT SPEAKER - EFFECT SPEAKER +
FIBER OPTIC CABLES
FL- DR HI/MID RANGE SPKR
FR- DR DEEP RANGE SPKR FL- DR DEEP RANGE SPKR
FUSE 9 FUSE 12 (UNDER RIGHT SIDE OF DASH)
GRN WIRE
GRN/BRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES LEFT FUSE 43 FUSE BOX (UNDER LEFT SIDE OF DASH)
INSTRUMENT PANEL CENTER WIDE-BAND SPEAKER
LEFT "D" PILLAR EFFECT SPEAKER
LEFT FRONT DOOR WOOFER
NCA WIRE
PLUS SWITCHED
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT "D" PILLAR EFFECT SPEAKER
RIGHT FRONT DOOR WOOFER
RIGHT FUSE BOX
SUBWOOFER
VNC - MICROPHONE
VNC SHIELD 4 5 6 7 8 9 10
WAKE-UP
WHT/BLK WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Bose radio circuit (4 of 4) -> 5 2 4 1 3 6 PLUS SWITCHED SIGNAL TERM 30 SIGNAL TERM 31
