Porsche Cayenne I facelift (2007-2010) 1 2 video signal shield Wiring diagrams
This page contains all the electrical diagrams for the component. 1 2 video signal shield, in which he is found in the car Porsche Cayenne I facelift (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
1 2 video signal shield wiring diagram (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 CAN HIGH INFOTAINMENT CAN LOW INFOTAINMENT
1 2 ADL SHIELD
1 2 HF HF SHIELD
1 2 HF SHIELD
1 2 VIDEO SIGNAL SHIELD
14 15 16 17 18 19 20 EMERGENCY CALL
2 1 4 3 MICROPHONE ANTENNA INPUT
ANTENNA INPUT
BLK WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
CELLULAR PHONES CIRCUIT
CELLULAR PHONES CIRCUIT W/ BASIC TELEPHONE
COMPUTER DATA LINES SYSTEM
CONTROL
DIV - SL
EMERGENCY CALL
FIBER OPTIC CABLES IN
FIBER OPTIC CABLES OUT
GPS ANTENNA
GRN WIRE
GRY/RED WIRE
GRY/WHT WIRE
HF IN HF SHIELD IN
HOT AT ALL TIMES RIGHT FUSE 11 FUSE BOX (UNDER RIGHT SIDE OF DASH)
INFO-NAVIGATION COMPUTER
LEFT DIVERSITY ANTENNA AMPLIFIER
NAVIGATION SYSTEM
NCA WIRE
NF TELEPHONE MICROPHONE GROUND MICROPHONE 1 +
NOISE ENTRY MICROPHONE
NOT USED) 1 2 3 4 5 6 7 8
ORG/BRN WIRE
ORG/VIO WIRE
REAR SPOILER ANTENNA
REAR WINDOW ANTENNA
RED WIRE
RED/YEL WIRE
RIGHT ANTENNA AMPLIFIER
ROOF CONSOLE
SUPPLY
TEL MUTE TERM 30 OUTPUT ANTENNA
TERM 31
W/O BASIC TELEPHONE
WAKE UP/DIAGNOSIS
WHT WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> Bose radio circuit (1 of 4) -> 1 2 VIDEO SIGNAL SHIELD
1 2 video signal shield wiring diagram (2 of 2)
