Porsche Cayenne I (2002-2007) Parking assistant circuit

BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM E BATTERY GROUND SIGNAL FRONT LEFT INSIDE PDC SENSOR FRONT LEFT MIDDLE PDC SENSOR FRONT LEFT OUTSIDE PDC SENSOR FRONT PDC DISPLAY FRONT RIGHT INSIDE PDC SENSOR FRONT RIGHT MIDDLE PDC SENSOR FRONT RIGHT OUTSIDE PDC SENSOR FUSE 2 GRY WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT REAR INSIDE PDC SENSOR LEFT REAR MIDDLE PDC SENSOR LEFT REAR OUTSIDE PDC SENSOR ORG/BRN WIRE ORG/GRN WIRE PARKING ASSIST SPEAKER PDC CONTROL UNIT (LEFT REAR CARGO AREA) PDC SENS GND PDC SENS GND PDC SENS SIG PDC SENS SIG PDC SENS SIG PDC SENS GND PDC SENS U-BATT PDC SENS U-BATT PDC SENS SIG PDC SENS GND PDC SWITCH PDC FUNCTION LIGHT PDC TERM 31 REAR PDC DISPLAY RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH) RIGHT REAR INSIDE PDC SENSOR RIGHT REAR MIDDLE PDC SENSOR RIGHT REAR OUTSIDE PDC SENSOR ROOF CONSOLE SUPPLY + GROUND SIGNAL TERM 30 CAN HIGH CAN LOW PDC DISPLAY GND PDC DISPLAY VOLTAGE PDC DISPLAY SIGNAL WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
