Interior lights circuit for Porsche Cayenne I (2002-2007)

BLK/BLU WIRE BLK/RED WIRE BLK/YEL WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE ENGINE COMPARTMENT LIGHT ENGINE HOOD FRONT FLAP SWITCH FOOTWELL LIGHTING BUTTON INSIDE LIGHTS FRONT INSTRUMENT PANEL OUTLETS FUSE 12 FUSE 53 GLOVE BOX LIGHT GLOVE BOX SWITCH GRY WIRE GRY/VIO WIRE HAZ WARN IND LIGHTS ENGINE HOOD SWITCH HAZARD SWITCH HOT AT ALL TIMES HOT IN ON AND START LEFT LEFT "B" PILLAR OUTLET LEFT FRONT FOOTWELL LIGHT LEFT FUSE BOX (UNDER LEFT SIDE OF DASH) LEFT REAR FOOTWELL LIGHTING LIGHT SWITCH MIDDLE ON-BOARD COMPUTER NETWORK CONTROL UNIT (UNDER LEFT SIDE OF DASH) RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT RIGHT "B" PILLAR OUTLET RIGHT FRONT FOOTWELL LIGHT RIGHT REAR FOOTWELL LIGHTING TERM 15 TERM 30 INSIDE LIGHT VIO/BLU WIRE YEL WIRE

BLU/WHT WIRE BRN WIRE BRN/WHT WIRE CENTER CONSOLE STORAGE COMPARTMENT DOOR CONTACT FRONT MIDDLE COCKPIT CIGAR LIGHTER PLUG SOCKET GRY WIRE INSIDE LIGHT LEFT MAKE-UP LIGHT LEFT REAR CENTER CONSOLE PLUG SOCKET LEFT REAR INSIDE LIGHT POTI GROUND POTI SIGNAL POTI SUPPLY REAR CENTER CONSOLE OUTLET RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE RIGHT MAKE-UP LIGHT RIGHT REAR CENTER CONSOLE CIGAR LIGHTER PLUG SOCKET RIGHT REAR INSIDE LIGHT ROOF CONSOLE RUNNING GEAR SWITCH MODULE SELECTOR LEVER SWITCH STORAGE COMPARTMENT LIGHT STORAGE COMPARTMENT SWITCH SW INSIDE LIGHTS VIO/BLU WIRE WHT/BLU WIRE YEL WIRE

BLK/RED WIRE BLU/YEL WIRE BRN WIRE BUTTON PANEL GRY WIRE LEFT FRONT CLS SAFE LEFT FRONT DOOR EXIT LIGHT LEFT FRONT DOOR HANDLE LIGHT LEFT FRONT DOOR PANEL LIGHTS LEFT FRONT DOOR WARNING LIGHT LEFT FRONT SEAT HEATER POTENTI- OMETER PASSENGER FOOTWELL PLUG SOCKET 1 PASSENGER FOOTWELL PLUG SOCKET 2 POWER WINDOWS, DOOR LOCK SYSTEMS PSM SWITCH RED WIRE RIGHT FRONT CENTRAL LOCKING BUTTON RIGHT FRONT CLS SAFE RIGHT FRONT DOOR EXIT LIGHT RIGHT FRONT DOOR HANDLE LIGHT RIGHT FRONT DOOR PANEL LIGHTS RIGHT FRONT DOOR WARNING LIGHT RIGHT FRONT POWER WINDOW SWITCH RIGHT FRONT SEAT HEATER POTENTI- OMETER RIGHT REAR SEAT HEATER POTENTI- OMETER TAILGATE SWITCH TANK COVER UNLOCKING SWITCH TERM 31 TRUNK, TAILGATE, FUEL DOORS SYSTEM WHT/VIO WIRE

BLK/RED WIRE BLU/YEL WIRE BRN WIRE DRIVER DOOR CONTROL UNIT GRY WIRE GRY/GRN WIRE LEFT REAR ASHTRAY LIGHT LEFT REAR POWER WINDOW SWITCH LEFT REAR CENTRAL LOCKING BUTTON LEFT REAR DOOR ENTRANCE LIGHT LEFT REAR DOOR HANDLE LIGHT LEFT REAR DOOR PANEL LIGHTS LEFT REAR DOOR WARNING LIGHT LEFT REAR HIGH DOOR CONTROL UNIT LEFT REAR SEAT HEATER POTENTI- OMETER PASSENGER DOOR CONTROL UNIT POWER WINDOWS, DOOR LOCK SYSTEMS RED WIRE RED/WHT WIRE RIGHT REAR ASHTRAY LIGHT RIGHT REAR CENTRAL LOCKING BUTTON RIGHT REAR DOOR ENTRANCE LIGHT RIGHT REAR DOOR HANDLE LIGHT RIGHT REAR DOOR PANEL LIGHTS RIGHT REAR DOOR WARNING LIGHT RIGHT REAR HIGH DOOR CONTROL UNIT RIGHT REAR POWER WINDOW SWITCH TERM 31 TERM 31 LOGIC TERM 31 CLS SAFE TERM 31 TAILGATE OPENER WHT/VIO WIRE

LEFT REAR DOOR SURROUND FLAP LIGHT LEFT REAR FLAP WARNING LIGHT LOADING SPACE LIGHT LUGGAGE COMPT LIGHT TURNING CASE REAR FLAP REAR COMFORT SYSTEMS CONTROL UNIT (RIGHT REAR CARGO AREA) RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT REAR DOOR SURROUND FLAP LIGHT RIGHT REAR FLAP WARNING LIGHT YEL WIRE
