Porsche Cayenne I (2002-2007) wash level sensor gnd wiring diagram
This page shows the only wiring diagram for the component.wash level sensor gnd, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
wash level sensor gnd wiring diagram (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
CAN-HIGH CAN-LOW
COMPUTER DATA LINES SYSTEM
DATA
DUAL WASH 1 DUAL WASH 2 TERM 31
FUSE 18
FUSE 52
FUSE 53
FUSE 8
FUSE 9
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/WHT WIRE
HEADLAMP CLEANER PUMP
HEADLAMP CLEANER RELAY
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
INTERMITTENT CONTROL
LEFT FUSE BOX (UNDER LEFT SIDE OF DASH)
LEFT WASHING JET
ON BOARD COMPUTER NETWORK CONTROL UNIT
ORG/BRN WIRE
ORG/VIO WIRE
RAIN SENSOR
REAR COMFORT SYSTEMS CONTROL UNIT
REAR WINDOW WIPER
REAR WIPER CONTROL
RED WIRE
RED/YEL WIRE
RELAY HCS
RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH) FUSE 44
RIGHT WASHING JET
SIGNAL
SUPPLY GROUND
SUPPLY GROUND DATA
TERM 15
TERM 30 AFL SUPPLY
TERM 30 TERM 31
TERM 31
TERM 31 INTERMITTENT CONTROL TERM 15
WASH LEVEL SENSOR GND
WASHER FLUID LEVEL SENSOR
WHT WIRE
WIPER MOTOR
Go to component -> Wiper/washer circuit -> WASH LEVEL SENSOR GND
