Porsche Cayenne I (2002-2007) term 31 term 31 logic term 31 cls safe term 31 tailgate opener Wiring diagram
This page shows the only wiring diagram for the component.term 31 term 31 logic term 31 cls safe term 31 tailgate opener, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram term 31 term 31 logic term 31 cls safe term 31 tailgate opener (1 of 1)
BLK/RED WIRE
BLU/YEL WIRE
BRN WIRE
DRIVER DOOR CONTROL UNIT
GRY WIRE
GRY/GRN WIRE
LEFT REAR ASHTRAY LIGHT LEFT REAR POWER WINDOW SWITCH
LEFT REAR CENTRAL LOCKING BUTTON
LEFT REAR DOOR ENTRANCE LIGHT
LEFT REAR DOOR HANDLE LIGHT
LEFT REAR DOOR PANEL LIGHTS
LEFT REAR DOOR WARNING LIGHT
LEFT REAR HIGH DOOR CONTROL UNIT
LEFT REAR SEAT HEATER POTENTI- OMETER
PASSENGER DOOR CONTROL UNIT
POWER WINDOWS, DOOR LOCK SYSTEMS
RED WIRE
RED/WHT WIRE
RIGHT REAR ASHTRAY LIGHT
RIGHT REAR CENTRAL LOCKING BUTTON
RIGHT REAR DOOR ENTRANCE LIGHT
RIGHT REAR DOOR HANDLE LIGHT
RIGHT REAR DOOR PANEL LIGHTS
RIGHT REAR DOOR WARNING LIGHT
RIGHT REAR HIGH DOOR CONTROL UNIT
RIGHT REAR POWER WINDOW SWITCH
TERM 31 TERM 31 LOGIC TERM 31 CLS SAFE TERM 31 TAILGATE OPENER
WHT/VIO WIRE
Go to component -> Interior lights circuit (4 of 5) -> TERM 31 TERM 31 LOGIC TERM 31 CLS SAFE TERM 31 TAILGATE OPENER
