Porsche Cayenne I (2002-2007) tele- phone prepar- ation Wiring diagram
This page shows the only wiring diagram for the component.tele- phone prepar- ation, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tele- phone prepar- ation (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BOSE AMPLIFIER
BRAKE BOOSTER
DVD DRIVE
E BOX HANDY
FROM FROM LEFT FUSE BOX, FUSE 51 (DIAGRAM 3 OF 10)
FROM MAIN FUSE BOX, FUSE 2 (DIAGRAM 1 OF 10)
FROM MAIN FUSE BOX, FUSE 3 (DIAGRAM 1 OF 10)
FUSE 10
FUSE 11
FUSE 12
FUSE 15 FUSE 14 FUSE 17
FUSE 18
FUSE 19
FUSE 2 FUSE 1
FUSE 3
FUSE 4
FUSE 47
FUSE 48
FUSE 49 FUSE 51
FUSE 5
FUSE 52
FUSE 6 FUSE 7
FUSE 8
FUSE 9
GEARBOX ASSEMBLY
INSIDE MIRROR TELEPHONE CONTROL UNIT TRANSMISSION
LEVEL CONTROL UNIT E-BOX HANDY
ON BOARD COMPUTER NETWORK CONTROL UNIT
PCM 2
PDC CONTROL UNIT
RADIO
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FUSE BOX (RIGHT SIDE OF DASH)
SATELLITE RECEIVER
SELECTOR LEVER SWITCH
TELE- PHONE PREPAR- ATION
TELEPHONE CONTROL UNIT
TO RIGHT FUSE BOX FUSE 21 (DIAGRAM 5 OF 10)
TO RIGHT FUSE BOX, FUSE 38 (DIAGRAM 6 OF 10)
TRAILER CONNECTION DEVICE
TRAILER CONNECTION DEVICE TELE- PHONE PREPAR- ATION
TRANSFER CASE CONTROL UNIT PSM CONTROL UNIT
TV TUNER CD CHANGER
Go to component -> Power distribution circuit (4 of 10) -> TELE- PHONE PREPAR- ATION
