Porsche Cayenne I (2002-2007) tank leak recognition device cooling fan 2 Wiring diagram
This page shows the only wiring diagram for the component.tank leak recognition device cooling fan 2, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tank leak recognition device cooling fan 2 (1 of 1)
AFTER RUN COOLANT PUMP RELAY
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN/GRN WIRE
CAMSHAFT ADJUSTMENT 1
CAMSHAFT ADJUSTMENT 2
COOLING FAN 1
E-BOX (LEFT REAR OF ENGINE COMPT)
EXTERNALLY CONTROLLED COMPRESSOR
FROM E-BOX, FUSE 8 (DIAGRAM 9 OF 10)
FROM E-BOX, MAIN RELAY 2 (DIAGRAM 9 OF 10)
FUSE 10
FUSE 11
FUSE 12
FUSE 17
FUSE 18
FUSE 9
GRY WIRE
LEFT/RIGHT CLIMATRONIC CONTROL UNIT
MOTOR CONTROL UNIT
OIL LEVEL SENSOR
OXYGEN SENSOR 1 (BEFORE CAT)
OXYGEN SENSOR 1 (BEHIND CAT)
OXYGEN SENSOR 2 (BEFORE CAT)
OXYGEN SENSOR 2 (BEHIND CAT)
PRESSURE SENSOR
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
SECONDARY AIR PUMP 1 RELAY
SECONDARY AIR PUMP 2 RELAY
SHIFT VALVE INTAKE PIPE CHANGE- OVER
TANK LEAK RECOGNITION DEVICE COOLING FAN 2
TANK VENTING VALVE
VACUUM PUMP RELAY
YEL WIRE
Go to component -> Power distribution circuit (10 of 10) -> TANK LEAK RECOGNITION DEVICE COOLING FAN 2
