Porsche Cayenne I (2002-2007) sunroof close tilt slide sunroof wiring diagram
This page shows the only wiring diagram for the component.sunroof close tilt slide sunroof, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
sunroof close tilt slide sunroof wiring diagram (1 of 1)
5 VOLTS GROUND SIGNAL
BLU/GRN WIRE
BRN WIRE
EMERGENCY CLOSE CODING
EMERGENCY CLOSE GROUND
FUSE 42
HOT AT ALL TIMES
INSTRUMENT CLUSTER
KL 58 KL 31
LEFT FUSE BOX (UNDER LEFT SIDE OF DASH)
NCA WIRE
REAR COMFORT SYSTEMS CONTROL UNIT (RIGHT REAR CARGO AREA)
RED/YEL WIRE
SPEED OUTPUT
SPEED SIGNAL
SUNROOF CLOSE TILT SLIDE SUNROOF
TERM 31
TERM 31 ENABLING COMFORT CLOSE TERM 30
TILT SLIDE SUNROOF
TILT SLIDE SUNROOF ILLUMINATED RING
TILT SLIDE SUNROOF SWITCH
WHT/VIO WIRE
YEL WIRE
Go to component -> Sunroof circuit -> SUNROOF CLOSE TILT SLIDE SUNROOF
