Porsche Cayenne I (2002-2007) starter generator Wiring diagram
This page shows the only wiring diagram for the component.starter generator, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram starter generator (1 of 1)
BLK WIRE
BRN WIRE
BRN/RED WIRE
CURRENT RAIL BATTERY WIRE
CURRENT RAIL L-FORM
CURRENT RAIL S-FORM
CURRENT RAIL STARTER WIRE
DIAG
DISENGAGEABLE STABILIZER CONTROL UNIT
DRIVER DOOR CONTROL UNIT
DRIVER IDENTIFICATION CONTROL UNIT
FROM LEFT FUSE BOX, FUSE 39 (DIAGRAM 2 OF 10)
FROM MAIN FUSE BOX, FUSE 1 (DIAGRAM 1 OF 10)
FUSE 1
FUSE 10
FUSE 11
FUSE 11 FUSE
FUSE 12
FUSE 13 FUSE 9
FUSE 14
FUSE 2
FUSE 3 FUSE 2
FUSE 4
FUSE 4 FUSE 7 TO LEFT FUSE BOX, FUSE 1 (DIAGRAM 8 OF 10)
FUSE 5
FUSE 7
FUSE 8
FUSE 9 FUSE 10
HIGH LEFT REAR DOOR CONTROL UNIT ON-BOARD COMPUTER NETWORK CONTROL UNIT
LEFT COCKPIT SUPPORT RELAY
LEFT FUSE BOX (LEFT SIDE OF DASH)
MAIN FUSE BOX (OVER VEHICLE ELECTRICAL SYSTEM BATTERY)
MAIN FUSE BOX (PRE-FUSE SOCKET) (OVER VEHICLE ELECTRICAL SYSTEM BATTERY)
MAIN FUSE BOX (REAR) (W/ PREPARATION STARTER BATTERY)
NCA WIRE
ON BOARD COMPUTER NETWORK CONTROL UNIT
ON-BOARD COMPUTER NETWORK CONTROL UNIT 3.2L 4.5L
POWER RELAY
PREPARATION STARTER BATTERY
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY 15 WITH DIAGNOSIS
RESIDUAL HEAT RELAY
STARTER GENERATOR
TERM 15 ACTUAT
TERM 15 DIAG
TERM 30
TERM 85
TERM 86
TERM 87
TO E-BOX, SH FUSE (DIAGRAM 8 OF 10)
TO FUSE 1 (DIAGRAM 9 OF 10) TO FUSE 1 (DIAGRAM 6 OF 10)
TO LEFT FUSE BOX, FUSE 14 (DIAGRAM 2 OF 10)
TO LEFT FUSE BOX, FUSE 2 (DIAGRAM 1 OF 10)
TO LEFT FUSE BOX, FUSE 47 (DIAGRAM 3 OF 10)
TRANSFER SOCKET
TYCO PARTITION ELEMENT
VEHICLE ELECTRICAL SYSTEM BATTERY
VIO WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 10) -> STARTER GENERATOR
