Porsche Cayenne I (2002-2007) sig blinds wiring diagram
This page shows the only wiring diagram for the component.sig blinds, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
sig blinds wiring diagram (1 of 1)
BLINDS MOTOR
BLINDS ROCKER SWITCH
BLK/BLU WIRE
BLU WIRE
BRN WIRE
CAN HIGH TERM 31
COMPUTER DATA LINES SYSTEM
FUSE 42
GRN WIRE
HALL SENS
HALL SENS 1 -
HALL SENS 2
HALL SENS 2 HALL SENS 1
HALL SENS GND MTR A HALL SENS 1 MTR B HALL SENS + HALL SENS 2
HOT AT ALL TIMES
KL 58 KL 31
LEFT FUSE BOX (LEFT SIDE OF DASH)
MTR A
MTR A GND MTR B HALL SENS +
MTR B
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PANORAMA ROOF SYSTEM CONTROL MODULE (FRONT CENTER OF ROOF)
PANORAMA ROOF SYSTEM ILLUMINATED SYMBOL RING
PANORAMA ROOF SYSTEM PRESELECTOR SWITCH (ROOF CONSOLE)
RED WIRE
RED/YEL WIRE
SIG
SIG BLINDS
SUN ROOF MOTOR 1
SUN ROOF MOTOR 2
TERM 30
TERM 31
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Panoramic roof circuit -> SIG BLINDS
