Porsche Cayenne I (2002-2007) secondary air pump 2 wiring diagram
This page shows the only wiring diagram for the component.secondary air pump 2, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
secondary air pump 2 wiring diagram (1 of 1)
BLK WIRE
BRN WIRE
CLOSING AID -
HIGH MOUNTED STOP LIGHT
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 4 IGNITION COIL 3
IGNITION COIL 4 SECONDARY AIR PUMP 1
IGNITION COIL 6 IGNITION COIL 7
IGNITION COIL 8
LEVEL CONTROL UNIT
MM (3.2L) (CENTER OF ENGINE COMPT)
PANORAMA ROOF SYSTEM CONTROL UNIT
REAR 2 + 2 BLOWER CONTROL UNIT
REAR AXLE HVAC SENSOR LEFT REAR BRAKE PAD SENSOR
REAR COMFORT SYSTEMS CONTROL UNIT
REAR FLAP HANDLE BUTTON
REAR LOCK
REAR LOCK TRAILER POWER SOCKET
REAR WINDOW BUTTON
REAR WINDOW DEFOGGER
RESERVE WHEEL CARRIER PUSH- BUTTON HANDLE SPARE WHEEL TURNING CASE SWITCH
RIGHT "D" PILLAR TAILS LIGHTS ASSEMBLY
RIGHT BOOT PLUG SOCKET
SECONDARY AIR PUMP 2
SPARE WHEEL LICENSE PLATE LIGHT
SPARE WHEEL LIMIT POSITION SWITCH
SPARE WHEEL RELEASE PDC CONTROL UNIT
TANK COVER UNLOCKING MOTOR
TANK FILLER NECK EARTH
TELESTART RECEIVER
TILT SENSOR
TRAILER CONNECTION DEVICE
TRAILER POWER SOCKET
TRANSFER CASE CONTROL UNIT
Go to component -> Ground distribution circuit (7 of 7) -> SECONDARY AIR PUMP 2
