Porsche Cayenne I (2002-2007) right seat well side bolster heating Wiring diagram
This page shows the only wiring diagram for the component.right seat well side bolster heating, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right seat well side bolster heating (1 of 1)
BACKREST SIDE- BOLSTER HEATER BACKREST SEAT HEATER
BLK WIRE
BOSE AUDIO OPTION PACK
BRN WIRE
BRN/WHT WIRE
CD CHANGER
DVD DRIVE
E BOX HANDY
FRONT PASS- ENGER'S
FRONT PASS- ENGER'S FRONT PASS- ENGER'S
FRONT PASS- ENGER'S SEAT HEATER CONTROL UNIT
GEARBOX CABLE PREINSTALLATION
LEFT REAR FLAP LICENSE PLATE LIGHT
METERING PUMP
MICROPHONE ENTRY NOISE SHIELD
NCA WIRE
NEUTRAL POSITION SWITCH
PASS- ENGER'S SEAT MEMORY
PASSENGER SEAT SWITCH MODULE
PASSENGER SIDE AIRBAG
PASSENGER'S SEAT HEATER
PCM 2
RADIO
REAR WINDOW DRIVE
REAR WINDOW TURNING CASE
RED WIRE
RIGHT BACKREST SIDE BOLSTER HEATING
RIGHT FRONT FOOTWELL LIGHT
RIGHT FRONT SEAT HEATER CONTROL UNIT
RIGHT HEATED BACKREST
RIGHT REAR FLAP LICENSE PLATE LIGHT
RIGHT REAR FOOTWELL LIGHT
RIGHT SEAT WELL SIDE BOLSTER HEATING
SATELLITE RECEIVER
SEAT WELL HEATER
SIDE BOLSTER HEATER
SUBWOOFER
TELEPHONE
TELEPHONE PREPARATION
TRANSFER CASE)
TRANSMISSION
TV TUNER
W/ MEMORY W/ HEIGHT ADJUSTMENT
W/O MEMORY , MEMORY W/O HEIGHT ADJUSTMENT
WABCO HP PLUS RIDE HEIGHT CONTROL COMPRESSOR
WHT WIRE
Go to component -> Ground distribution circuit (4 of 7) -> RIGHT SEAT WELL SIDE BOLSTER HEATING
