Porsche Cayenne I (2002-2007) right rear center console cigar lighter plug socket Wiring diagram
This page shows the only wiring diagram for the component.right rear center console cigar lighter plug socket, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear center console cigar lighter plug socket (1 of 1)
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CENTER CONSOLE STORAGE COMPARTMENT
DOOR CONTACT
FRONT MIDDLE COCKPIT CIGAR LIGHTER PLUG SOCKET
GRY WIRE
INSIDE LIGHT
LEFT MAKE-UP LIGHT
LEFT REAR CENTER CONSOLE PLUG SOCKET
LEFT REAR INSIDE LIGHT
POTI GROUND
POTI SIGNAL
POTI SUPPLY
REAR CENTER CONSOLE OUTLET
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT MAKE-UP LIGHT
RIGHT REAR CENTER CONSOLE CIGAR LIGHTER PLUG SOCKET
RIGHT REAR INSIDE LIGHT
ROOF CONSOLE
RUNNING GEAR SWITCH MODULE
SELECTOR LEVER SWITCH
STORAGE COMPARTMENT LIGHT
STORAGE COMPARTMENT SWITCH
SW INSIDE LIGHTS
VIO/BLU WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Interior lights circuit (2 of 5) -> RIGHT REAR CENTER CONSOLE CIGAR LIGHTER PLUG SOCKET
