Porsche Cayenne I (2002-2007) rear flap drive Wiring diagram
This page shows the only wiring diagram for the component.rear flap drive, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear flap drive (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLU/GRN WIRE
BRN WIRE
BRN/YEL WIRE
CLOSING AID -
CLOSING AID RELAY
COMPUTER DATA LINES SYSTEM
FUSE 21
FUSE 30
FUSE 31
FUSE 53
GRN WIRE
HOT AT ALL TIMES
HOT IN RUN AND START
HR VR TERM 31
LEFT FUSE BOX (UNDER LEFT SIDE OF DASH)
ORG/BRN WIRE
ORG/GRN WIRE
REAR COMFORT SYSTEMS CONTROL UNIT (RIGHT REAR CARGO AREA)
REAR FLAP DRIVE
REAR FLAP HANDLE PUSHBUTTON
RED/YEL WIRE
RESERVE WHEEL CARRIER HANDLE PUSHBUTTON
RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH)
SPARE WHEEL LIMIT SWITCH
SPARE WHEEL RELEASE
SPARE WHEEL RELEASE RELAY
SPARE WHEEL TURNING CASE SWITCH
TANK COVER UNLOCKING
TRAILER REAR LOCK
VIO/YEL WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Trunk, tailgate, fuel door circuit -> REAR FLAP DRIVE
