Porsche Cayenne I (2002-2007) rear comfort systems control unit high right rear door control unit Wiring diagram
This page shows the only wiring diagram for the component.rear comfort systems control unit high right rear door control unit, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear comfort systems control unit high right rear door control unit (1 of 1)
BACKUP HORN
CLIMATRONIC CONTROL UNIT
CLOSING AID RELAY
COMPASS
FROM RIGHT FUSE BOX, FUSE 5 (DIAGRAM 4 OF 10)
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 27
FUSE 29
FUSE 30
FUSE 32 FUSE 31
FUSE 35 FUSE 34
FUSE 36
FUSE 56
FUSE 57
LEVEL CONTROL UNIT
ON-BOARD COMPUTER NETWORK CONTROL UNIT PASSENGER DOOR CONTROL UNIT
PASS- ENGER'S LUMBAR SWITCH
PASS- ENGER'S SEAT HEATER CONTROL UNIT
PASS- ENGER'S SEAT MEMORY
PASS- ENGER'S SEAT SWITCH MODULE
PSM CONTROL UNIT
REAR CLIMATRONIC CONTROL UNIT 2 + 2
REAR COMFORT SYSTEMS CONTROL UNIT HIGH RIGHT REAR DOOR CONTROL UNIT
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FUSE BOX (RIGHT SIDE OF DASH)
RIGHT REAR SEAT HEATER CONTROL UNIT
SPARE WHEEL RELEASE RELAY
TELEPHONE ROOF MODULE
TRANS- MISSION CONTROL UNIT SELECTOR LEVER SWITCH
TRANSFER CASE)
Go to component -> Power distribution circuit (5 of 10) -> REAR COMFORT SYSTEMS CONTROL UNIT HIGH RIGHT REAR DOOR CONTROL UNIT
