Porsche Cayenne I (2002-2007) rear axle hvac sensor front axle hvac sensor Wiring diagram
This page shows the only wiring diagram for the component.rear axle hvac sensor front axle hvac sensor, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear axle hvac sensor front axle hvac sensor (1 of 1)
AIR QUALITY SENSOR
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
CRANKCASE VENTILATION HEATER SHIFT VALVE (3.2L)
DIAGNOSIS PLUG SOCKET
DISENGAGEABLE STABILIZER CONTROL UNIT
DRIVER'S LUMBAR SWITCH
DRIVER'S SEAT HEATER CONTROL UNIT
DRIVER'S SEAT SWITCH MODULE
FROM LEFT FUSE BOX FUSE 21 (DIAGRAM 2 OF 10)
FROM RELAY 15 WITH DIAGNOSIS (DIAGRAM 1 OF 10)
FUSE 33
FUSE 34
FUSE 35
FUSE 36
FUSE 42
FUSE 43
FUSE 44
FUSE 45
FUSE 47
FUSE 49
FUSE 50
FUSE 51
FUSE 52
FUSE 53
FUSE 54
INTERIOR SENSOR
LEFT FUSE BOX (LEFT SIDE OF DASH)
LEFT REAR SEAT HEATER CONTROL UNIT DRIVER'S SEAT SWITCH MODULE
LEFT REAR SUBWOOFER LOADING SPACE
ON BOARD COMPUTER NETWORK CONTROL UNIT
PANORAMA ROOF SYSTEM CONTROL UNIT
PARKING BRAKE SWITCH
REAR AXLE HVAC SENSOR FRONT AXLE HVAC SENSOR
REAR COMFORT SYSTEMS CONTROL UNIT
REAR WINDOW WIPER
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT (OR RED/YEL) WIRE
RED/WHT WIRE
RED/YEL WIRE
SEAT MEMORY
SERVTRONIC CONTROL UNIT
STEERING COLUMN SWITCH MODULE
STEERING COLUMN SWITCH MODULE LIGHT SWITCH
TILT SENSOR
TILT SLIDE SUNROOF
TO RIGHT FUSE BOX, FUSE 47 (DIAGRAM 4 OF 10)
TRANSFER CASE CONTROL UNIT
Go to component -> Power distribution circuit (3 of 10) -> REAR AXLE HVAC SENSOR FRONT AXLE HVAC SENSOR
