Porsche Cayenne I (2002-2007) preparation brake booster Wiring diagrams
This page contains all the electrical diagrams for the component. preparation brake booster, in which he is found in the car Porsche Cayenne I (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram preparation brake booster (1 of 2)
3.2L
BACK-UP HORN
BRAKE FLUID SENSOR RESIDUAL HEAT RELAY
BRN WIRE
CIRCULATION PUMP RELAY
CLOSING AID RELAY
DRIVER IDENTIFICATION CONTROL UNIT
FRONT LEFT FOOTWELL LIGHT
FRONT LEFT INSTRUMENT PANEL OUTLET
FRONT MIDDLE COCKPIT CIGAR LIGHTER PLUG SOCKET
GATEWAY CONTROL UNIT LIGHT SWITCH
GRN WIRE
HAZARD WARNING SWITCH
HEADLIGHT CLEANER RELAY
INSTRUMENT CLUSTER
LEFT FRONT SEAT HEATER POTENTIOMETER
OIL LEVEL SENSOR
ON BOARD COMPUTER NETWORK CONTROL UNIT
PCM 2
PREPARATION BRAKE BOOSTER
PSM SWITCH
RIGHT FRONT SEAT HEATER POTENTIOMETER
SERVTRONIC RELAY
SIGNAL HORN
SPARE WHEEL RELEASE RELAY
STEERING COLUMN SWITCH MODULE
Go to component -> Ground distribution circuit (3 of 7) -> PREPARATION BRAKE BOOSTER
Wiring diagram preparation brake booster (2 of 2)
BACKUP LIGHT
BACKUP SIGNAL
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CAN HIGH CAN LOW BRAKELIGHT SWITCH
COMPUTER DATA LINES SYSTEM
ELEC BRAKE
FUSE 1
FUSE 19
FUSE 3
FUSE 41
FUSE 5
GRN WIRE
HOT AT ALL TIMES
HOT IN RUN AND START
LEFT REAR TURN SIG
LEFT TURN SIGNALS/BRAKE
ORG/BRN WIRE
ORG/GRN WIRE
PREPARATION BRAKE BOOSTER
PSM CONTROL UNIT (RIGHT REAR OF ENGINE COMPT)
REAR COMFORT SYSTEMS CONTROL UNIT (RIGHT REAR CARGO AREA)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RFS TRAILER
RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH)
RIGHT REAR LIGHTS
RIGHT REAR TURN SIG
RIGHT TURN SIGNALS/BRAKE
STOPLIGHT
TERM 30 STOPLIGHTS ELEC BRAKE TERM 31
TERM 30 SWITCHED
TERM 31
TERM 31 CAN LOW CAN HIGH
TRAILER CONNECTION DEVICE
TRAILER POWER SOCKET
YEL WIRE
Go to component -> Trailer tow circuit -> PREPARATION BRAKE BOOSTER
