Porsche Cayenne I (2002-2007) passenger's side seat switch module Wiring diagram
This page shows the only wiring diagram for the component.passenger's side seat switch module, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's side seat switch module (1 of 1)
AUTO FUSE
BACKREST LUMBAR HORIZONTAL MOTOR (FORWARD)
BACKREST LUMBAR VERTICAL MOTOR (UP)
BACKREST MOTOR (FORWARD)
BACKREST SEAT HEIGHT TERM 31
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DIODE
ENABLING SEAT HEATER SIG
FUSE 22
FUSE 24
FUSE 44
GENERATOR
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
HEATER
HOT AT ALL TIMES
HOT IN RUN OR START
LONGITUDINAL MOTOR (UP)
LUMBAR VERTICAL 1 MTR LUMBAR VERTICAL 2 MTR LUMBAR HORIZONTAL 1 MTR
NCA WIRE
NTC + GND
NTC-
PASSENGER'S SIDE SEAT SWITCH MODULE
REAR SEAT HEATER CIRCUIT
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT SEAT BACKREST HEATER (W/ HEATED SEATS)
RIGHT FRONT SEAT BACKREST SIDE BOLSTER HEATER (W/ HEATED SEATS)
RIGHT FRONT SEAT HEATER CONTROL UNIT (W/ HEATED SEATS)
RIGHT FRONT SEAT HEATER POTENTIOMETER (W/ HEATED SEATS)
RIGHT FRONT SEAT WELL HEATER (W/ HEATED SEATS)
RIGHT FRONT SEAT WELL SIDE BOLSTER HEATER (W/ HEATED SEATS)
RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH)
SEAT HEIGHT ADJUSTMENT MOTOR (FORWARD)
SEAT INCLINATION MOTOR (UP)
TERM 15 PS K ENABLING
TERM 31 HEATER
TERM 31 LUMBAR LONGITUDINAL INCLINATION TERM 31
TERM 31 TERM 30
Go to component -> Passenger power seat circuit -> PASSENGER'S SIDE SEAT SWITCH MODULE
