Porsche Cayenne I (2002-2007) motor + motor - term 31 camera - camera + flash flash Wiring diagram
This page shows the only wiring diagram for the component.motor + motor - term 31 camera - camera + flash flash, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram motor + motor - term 31 camera - camera + flash flash (1 of 1)
BACKUP CAMERA CONTROL UNIT
BLU WIRE
BRN WIRE
CAMERA
CAMERA + CAMERA - MOTOR + MOTOR -
FUSE 55
HOT AT ALL TIMES
INFO-NAVIGATION COMPUTER
MOTOR + MOTOR - TERM 31 CAMERA - CAMERA + FLASH FLASH
NCA WIRE
RED/YEL WIRE
RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH)
SHIELD
SIGNAL
TERM 30 SIGNAL EXTEND
TV TUNER
VIDEO SIGNAL
Go to component -> Rear camera circuit -> MOTOR + MOTOR - TERM 31 CAMERA - CAMERA + FLASH FLASH
