Porsche Cayenne I (2002-2007) left rear door high range speaker Wiring diagram
This page shows the only wiring diagram for the component.left rear door high range speaker, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear door high range speaker (1 of 1)
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
CD CHANGER (IF EQUIPPED)
DVD DRIVE
FIBER OPTIC
FIBER OPTIC TELEPHONE
FIBER OPTICS
FIBER OPTICS FIBER OPTIC CABLES IN
FIBER OPTICS FIBER OPTIC CABLES OUT
FIBER OPTICS FIBER OPTICS
FIBER OPTICS FIBER OPTICS FIBER OPTICS
FIBER OPTICS FIBER OPTICS FIBER OPTICS FIBER OPTICS
GRN WIRE
GRN/BRN WIRE
INSTRUMENT PANEL LEFT HIGH RANGE SPEAKER
INSTRUMENT PANEL RIGHT HIGH RANGE RADIO SPEAKER
LEFT FRONT DOOR MIDDLE RANGE SPEAKER
LEFT REAR DOOR HIGH RANGE SPEAKER
LEFT REAR DOOR MIDDLE RANGE SPEAKER
LOADING SPACE SUBWOOFER
LWL IN
LWL OUT
NCA WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT DOOR MIDDLE RANGE SPEAKER
RIGHT REAR DOOR HIGH RANGE SPEAKER
RIGHT REAR DOOR MIDDLE RANGE SPEAKER
SATELLITE RADIO CIRCUIT
SHIELD
SIGNAL SIGNAL TERM 31 TERM 30 PLUS SWITCHED
TELEPHONE
TERM 30
TERM 30 TERM 31 WAKE UP DIAGNOSIS
TERM 31
TV TUNER
WAKEUP/GIAG
WHT/BRN WIRE
WHT/RED WIRE
Go to component -> Bose radio circuit (2 of 3) -> LEFT REAR DOOR HIGH RANGE SPEAKER
