Porsche Cayenne I (2002-2007) hot in run, start Wiring diagrams
This page contains all the electrical diagrams for the component. hot in run, start, in which he is found in the car Porsche Cayenne I (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hot in run, start (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BOOSTER/ DISPLACEMENT SENSOR
BRN WIRE
BRN/WHT WIRE
CAN DRIVE LOW BODY GROUND SOL VALVE + PRESS SENSOR + PRESS SENSOR - PRESSURE SIG
CLUTCH SW PARK BRAKE SW RR SPEED SENSOR RR ROTATION SIG
CLUTCH SWITCH
CODES BRIDGE LR WHL SPEED OUT CAN DRIVE HIGH RF WHL SPEED OUT PSM SWITCH OFF
COMPUTER DATA LINES SYSTEM
FUSE 26
FUSE 38
FUSE 51
FUSE 56
GRN WIRE
GRN/BLK WIRE
GRN/VIO WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN, START
INSTRUMENT CLUSTER
LEFT FRONT WHEEL SENSOR
LEFT FUSE BOX (UNDER LEFT SIDE OF DASH) FUSE 49
LF ROTATION SIG LF SPEED SENSOR BODY GROUND
MULTIPLE SENSOR
ORG/BLK WIRE
ORG/BRN WIRE
ORG/VIO WIRE
PARKING BRAKE SWITCH
PORSCHE STABILITY MANAGEMENT (PSM) CONTROL UNIT
PRESSURE SENSOR
PSM SWITCH
RED WIRE
RED/YEL WIRE
RIGHT FRONT WHEEL SENSOR
RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH) FUSE 6
RIGHT REAR WHEEL SENSOR LEFT REAR WHEEL SENSOR
SERVOTRONIC RELAY MODULE
SERVOTRONIC TRANSDUCER
TERM 15
TERM 31
WAY SENSOR GND SENSOR SUPPLY
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti-lock brakes circuit -> HOT IN RUN, START
Wiring diagram hot in run, start (2 of 2)
Go to component -> Electronic power steering circuit -> HOT IN RUN, START
