Porsche Cayenne I (2002-2007) fuse 40 fuse 41 Wiring diagram
This page shows the only wiring diagram for the component.fuse 40 fuse 41, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 40 fuse 41 (1 of 1)
AIRBAG CONTROL UNIT TYCO SWITCH PARTITION ELEMENT
AIRBAG OFF DISPLAY
BLK WIRE
BLK/BLU WIRE
CLUTCH SWITCH
COMFORT SYSTEMS REAR CONTROL UNIT
DISENGAGEABLE STABILIZER CONTROL UNIT
DRIVER DOOR CONTROL UNIT
DRIVER IDENTIFICATION CONTROL UNIT
FROM LEFT FUSE BOX FUSE 7 (DIAGRAM 1 OF 10)
FRONT BLOWER MOTOR
FUSE 14
FUSE 15
FUSE 16
FUSE 18
FUSE 19 FUSE 17
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 26
FUSE 38
FUSE 39
FUSE 40 FUSE 41
FUSE 56
FUSE 57
HEADLIGHT CLEANER PUMP RELAY
HOT FILM AIR MASS METER (3.2L)
HOT-FILM AIR MASS METER 2
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER WEIGHT RECOGNITION CONTROL UNIT GATEWAY CONTROL UNIT
LEFT FUSE BOX (LEFT SIDE OF DASH)
MOTOR CONTROL UNIT
ON BOARD COMPUTER NETWORK CONTROL UNIT
REAR BLOWER MOTOR
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
TIRE PRESSURE CONTROL UNIT
TO LEFT FUSE BOX, FUSE 33 (DIAGRAM 3 OF 10)
TO RELAY 15 WITH DIAGNOSIS (DIAGRAM 1 OF 10)
TRANSFER CASE CONTROL UNIT
WEIGHT RECOGNITION CONTROL UNIT
Go to component -> Power distribution circuit (2 of 10) -> FUSE 40 FUSE 41
