Porsche Cayenne I (2002-2007) fuse 36 Wiring diagrams

BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRONIC COMPASS FUSE 36 HOT AT ALL TIMES ORG/BRN WIRE ORG/VIO WIRE RED/YEL WIRE RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH) TERM 30 TERM 31 CAN LOW INFO TERM 31 CAN HIGH INFO TERM 31

AFL SUPPLY BLK WIRE BRN WIRE DUAL WASH 2 DUAL WASH 1 ENABLING SEAT HEATER SIGNAL EMERGENCY START SIGNAL FUSE 10 FUSE 9 FUSE 11 FUSE 12 FUSE 9 FUSE 16 FUSE 36 FUSE 8 GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRY/VIO WIRE GRY/WHT WIRE HAZARD WARNING IND LIGHTS HEADLIGHTS SYSTEM HORNS SYSTEM HOT AT ALL TIMES INTERIOR LIGHTS SYSTEM WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM LEFT FUSE BOX (UNDER LEFT SIDE OF DASH) LOAD RELAY MAIN FUSE BOX (OVER VEHICLE ELECTRICAL SYSTEM BATTERY) MEASURING SIG VEHICLE ELEC SYS BATT ON BOARD COMPUTER NETWORK CONTROL UNIT PLUG SOCKET TWO TONE HORN RED WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH) SEATS SYSTEM TERM 30 ADDITIONAL HIGH BEAM ADDITIONAL HIGH BEAM TERM 30 BSG VEHICLE ELEC SYS BATT TERM 30 BSG BATT/STARTER TERM 31 BSG TERM 30 DUAL WASHING PUMP TERM 30 INSIDE LIGHT TERM 30 TWO TONE HORN TERM 31 DUAL WASHING PUMP VIO WIRE WHT WIRE WIPER/WASHER SYSTEM

BLK/BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE FUSE 36 FUSE 42 GRY WIRE HOT AT ALL TIMES HOT IN ON AND START INTERIOR LIGHTS SYSTEM MIRRORS SYSTEM NAVIGATION SYSTEM NAVIGATION SYSTEM (PARKING ASSISST CIRCUIT) RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH) ROOF CONSOLE TERM 15 VIO/BLU WIRE YEL WIRE YEL/GRN WIRE

AIR QUALITY SENSOR BLK WIRE BLK/BLU WIRE BLK/VIO WIRE CRANKCASE VENTILATION HEATER SHIFT VALVE (3.2L) DIAGNOSIS PLUG SOCKET DISENGAGEABLE STABILIZER CONTROL UNIT DRIVER'S LUMBAR SWITCH DRIVER'S SEAT HEATER CONTROL UNIT DRIVER'S SEAT SWITCH MODULE FROM LEFT FUSE BOX FUSE 21 (DIAGRAM 2 OF 10) FROM RELAY 15 WITH DIAGNOSIS (DIAGRAM 1 OF 10) FUSE 33 FUSE 34 FUSE 35 FUSE 36 FUSE 42 FUSE 43 FUSE 44 FUSE 45 FUSE 47 FUSE 49 FUSE 50 FUSE 51 FUSE 52 FUSE 53 FUSE 54 INTERIOR SENSOR LEFT FUSE BOX (LEFT SIDE OF DASH) LEFT REAR SEAT HEATER CONTROL UNIT DRIVER'S SEAT SWITCH MODULE LEFT REAR SUBWOOFER LOADING SPACE ON BOARD COMPUTER NETWORK CONTROL UNIT PANORAMA ROOF SYSTEM CONTROL UNIT PARKING BRAKE SWITCH REAR AXLE HVAC SENSOR FRONT AXLE HVAC SENSOR REAR COMFORT SYSTEMS CONTROL UNIT REAR WINDOW WIPER RED WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT (OR RED/YEL) WIRE RED/WHT WIRE RED/YEL WIRE SEAT MEMORY SERVTRONIC CONTROL UNIT STEERING COLUMN SWITCH MODULE STEERING COLUMN SWITCH MODULE LIGHT SWITCH TILT SENSOR TILT SLIDE SUNROOF TO RIGHT FUSE BOX, FUSE 47 (DIAGRAM 4 OF 10) TRANSFER CASE CONTROL UNIT

BACKUP HORN CLIMATRONIC CONTROL UNIT CLOSING AID RELAY COMPASS FROM RIGHT FUSE BOX, FUSE 5 (DIAGRAM 4 OF 10) FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 25 FUSE 27 FUSE 29 FUSE 30 FUSE 32 FUSE 31 FUSE 35 FUSE 34 FUSE 36 FUSE 56 FUSE 57 LEVEL CONTROL UNIT ON-BOARD COMPUTER NETWORK CONTROL UNIT PASSENGER DOOR CONTROL UNIT PASS- ENGER'S LUMBAR SWITCH PASS- ENGER'S SEAT HEATER CONTROL UNIT PASS- ENGER'S SEAT MEMORY PASS- ENGER'S SEAT SWITCH MODULE PSM CONTROL UNIT REAR CLIMATRONIC CONTROL UNIT 2 + 2 REAR COMFORT SYSTEMS CONTROL UNIT HIGH RIGHT REAR DOOR CONTROL UNIT RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FUSE BOX (RIGHT SIDE OF DASH) RIGHT REAR SEAT HEATER CONTROL UNIT SPARE WHEEL RELEASE RELAY TELEPHONE ROOF MODULE TRANS- MISSION CONTROL UNIT SELECTOR LEVER SWITCH TRANSFER CASE)
