Porsche Cayenne I (2002-2007) front middle instrument panel outlet Wiring diagram
This page shows the only wiring diagram for the component.front middle instrument panel outlet, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front middle instrument panel outlet (1 of 1)
AIR QUALITY SENSOR
BRN WIRE
FRONT 2 + 2 BLOWER CONTROL UNIT
FRONT 2 + 2 CLIMATRONIC CONTROL UNIT
FRONT MIDDLE INSTRUMENT PANEL OUTLET
FRONT RIGHT INSTRUMENT PANEL OUTLET
GLOVE BOX LIGHT
LEFT REAR CENTER CONSOLE PLUG SOCKET RIGHT REAR CENTER CONSOLE PLUG SOCKET
LEFT REAR SEAT HEATER POTENTIOMETER
LEFT/RIGHT BLOWER CONTROL UNIT
LEFT/RIGHT CLIMATRONIC CONTROL UNIT
MANUAL A/C BLOWER CONTROL UNIT
MANUAL CLIMATRONIC CONTROL UNIT
NCA WIRE
PARKING BRAKE SWITCH
PASSENGER DOOR CONTROL UNIT
PASSENGER FOOTWELL PLUG SOCKET 1 FRONT RIGHT FOOTWELL LIGHT
PASSENGER FOOTWELL PLUG SOCKET 2
REAR 2 +2 CLIMATRONIC CONTROL UNIT
REAR CENTER CONSOLE OUTLET
RIGHT REAR SEAT HEATER POTENTIOMETER
RUNNING GEAR SWITCH MODULE
SELECTOR LEVER SWITCH
STORAGE COMPART- MENT LIGHT
Go to component -> Ground distribution circuit (2 of 7) -> FRONT MIDDLE INSTRUMENT PANEL OUTLET
