Porsche Cayenne I (2002-2007) front driver's side "b" pillar control unit sensor Wiring diagram
This page shows the only wiring diagram for the component.front driver's side "b" pillar control unit sensor, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front driver's side "b" pillar control unit sensor (1 of 1)
3.2L
4.5L
AIRBAG CONTROL UNIT
AIRBAG OFF SWITCH
BLK WIRE
BRN WIRE
DRIVER BELT LOCK
DRIVER HEAD AIRBAG
FRONT DRIVER'S SIDE "B" PILLAR CONTROL UNIT SENSOR
FRONT DRIVER'S SIDE CONTROL UNIT SENSOR
FRONT PASSENGER'S SIDE "B" PILLAR CONTROL UNIT SENSOR
FRONT PASSENGER'S SIDE CONTROL UNIT SENSOR
LEFT OUTPUT SENSOR
NCA WIRE
PASSENGER AIRBAG
PASSENGER BELT LOCK
PASSENGER HEAD AIRBAG
PRESSURE SENSOR
REAR CLIMATRONIC 2 + 2 CONTROL UNIT
REAR DRIVER'S SIDE "C" PILLAR CONTROL UNIT SENSOR
REAR PASSENGER'S SIDE "C" PILLAR CONTROL UNIT SENSOR
RIGHT "B" PILLAR OUTLET
RIGHT OUTPUT SENSOR
RIGHT REAR BACKREST HEATER
RIGHT REAR BACKREST SIDE-BOLSTER HEATER
RIGHT REAR HIGH DOOR CONTROL UNIT
RIGHT REAR SEAT HEATER CONTROL UNIT
RIGHT REAR SEAT WELL SEAT HEATER
RIGHT REAR SEAT WELL SIDE-BOLSTER HEATER
STATIONARY HEATER CONTROL UNIT
TO LEFT REAR SEAT WELL SEAT HEATER (DIAGRAM 6 OF 7)
VACUUM PUMP
WEIGHT RECOGNITION CONTROL UNIT
Go to component -> Ground distribution circuit (5 of 7) -> FRONT DRIVER'S SIDE "B" PILLAR CONTROL UNIT SENSOR
