Porsche Cayenne I (2002-2007) extent cable preinstallation seat Wiring diagram
This page shows the only wiring diagram for the component.extent cable preinstallation seat, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram extent cable preinstallation seat (1 of 1)
AIR BAG
AIR BAG OFF DISPLAY
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE FRONT B-PILLAR CONTROL UNIT SENSOR
ESD
EXTENT CABLE PREINSTALLATION SEAT
FUSE 40
GRN WIRE
GROUND
GROUND POINT
HOT AT ALL TIMES LEFT FUSE BOX (UNDER LEFT SIDE OF DASH)
INPUT
LEFT FRONT WEIGHT SENSOR
LEFT REAR WEIGHT SENSOR
LIN
LIN AIRBAG
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER BELT LOCK
PASSENGER MORE BELT- TAUTLY (SEAT BELT TENSIONER)
RED HW-PFAD WIRE
RED WIRE
RED/YEL WIRE
RIGHT FRONT WEIGHT SENSOR
RIGHT REAR WEIGHT SENSOR
SIGNAL
SUPPLY
TERM 15
TERM 30
TERM 31
VIO/WHT WIRE
WEIGHT RECOGNITION CONTROL UNIT (IF EQUIPPED) (UNDER FRONT PASSENGER SEAT)
WHT WIRE
WHT/YEL WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> EXTENT CABLE PREINSTALLATION SEAT
