Porsche Cayenne I (2002-2007) enabling term 31 term 30 Wiring diagram
This page shows the only wiring diagram for the component.enabling term 31 term 30, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram enabling term 31 term 30 (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
DIODE
DRIVER POWER SEAT CIRCUIT, MEMORY SYSTEMS
ENABLING SEAT HEATER SIG
ENABLING TERM 31 TERM 30
FUSE 22
FUSE 44
FUSE 45
GENERATOR
GRN WIRE
GRN/RED WIRE
GROUND SENSOR
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LEFT FUSE BOX (UNDER LEFT SIDE OF DASH)
LEFT OUTSIDE SENSOR
LEFT REAR SEAT BACKREST HEATER
LEFT REAR SEAT BACKREST SIDE BOLSTER HEATER
LEFT REAR SEAT HEATER CONTROL UNIT
LEFT REAR SEAT HEATER POTENTIOMETER
LEFT REAR SEAT WELL HEATER
LEFT REAR SEAT WELL SIDE-BOLSTER HEATER
NCA WIRE
NTC GND NTC
NTC GROUND NTC TERM 31 HEATER
ON-BOARD COMPUTER NETWORK CONTROL UNIT (UNDER LEFT SIDE OF DASH)
REAR 2 +2 CLIMATRONIC CONTROL UNIT
RED WIRE
RED/WHT WIRE
RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH)
RIGHT OUTSIDE SENSOR
RIGHT REAR SEAT BACKREST HEATER
RIGHT REAR SEAT BACKREST SIDE BOLSTER HEATER
RIGHT REAR SEAT HEATER CONTROL UNIT
RIGHT REAR SEAT HEATER POTENTIOMETER
RIGHT REAR SEAT WELL HEATER
RIGHT REAR SEAT WELL SIDE-BOLSTER HEATER
SEAT HEATER LEFT
SEAT HEATER RIGHT
TEMP SENSOR
TERM 1 HEATER
TERM 15 PS K
Go to component -> Rear seat heater circuit -> ENABLING TERM 31 TERM 30
