Porsche Cayenne I (2002-2007) + drive motors drive motor x axis Wiring diagram
This page shows the only wiring diagram for the component.+ drive motors drive motor x axis, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram + drive motors drive motor x axis (1 of 1)
+ DRIVE MOTORS DRIVE MOTOR X AXIS
+ DRIVE MOTORS DRIVE MOTORS X-AXIS
BACK-UP LIGHT SWITCH
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BRN WIRE
BRN/GRN WIRE
DRIVER DOOR CONTROL UNIT
DRIVER'S SIDE OUTSIDE MIRROR
EC MIRROR
EC+ EC-
FUSE 49
GRY WIRE
GRY/GRN WIRE
GRY/VIO WIRE
HEATER
HOT IN RUN AND START
INSIDE MIRROR
MIRROR HEATING
MOTOR CONTROL X/Y MOTOR CONTROL X TURN SIGNALS SUPPLY POTI STATUS POS Y
ON-BOARD COMPUTER NETWORK CONTROL UNIT (UNDER LEFT SIDE OF DASH)
PASSENGER DOOR CONTROL UNIT
PASSENGER'S SIDE OUTSIDE MIRROR
POTI + POTI POS Y AXIS
POTI - GROUND FOLD IN MIRRORS DRIVE MOTOR Y AXIS SURROUND LIGHTS
POTI - GROUND FOLD IN MIRRORS DRIVE MOTORS Y-AXIS SURROUND LIGHTS
POTI POS X AXIS
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH)
ROOF CONSOLE
STATUS POS X
TERM 15 TERM 31 ENABLING EC MIRROR + EC MIRROR - INSIDE LIGHTS
TERM 31 POTI GROUND FOLDING MIRROR MOTOR CONTROL Y SURROUND LIGHTS
VIO WIRE
WHT WIRE
YEL WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Power mirrors circuit -> + DRIVE MOTORS DRIVE MOTOR X AXIS
