Porsche Cayenne I (2002-2007) current rail s-form Wiring diagrams
This page contains all the electrical diagrams for the component. current rail s-form, in which he is found in the car Porsche Cayenne I (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram current rail s-form (1 of 2)
BLK WIRE
BRN WIRE
BRN/RED WIRE
CURRENT RAIL BATTERY WIRE
CURRENT RAIL L-FORM
CURRENT RAIL S-FORM
CURRENT RAIL STARTER WIRE
DIAG
DISENGAGEABLE STABILIZER CONTROL UNIT
DRIVER DOOR CONTROL UNIT
DRIVER IDENTIFICATION CONTROL UNIT
FROM LEFT FUSE BOX, FUSE 39 (DIAGRAM 2 OF 10)
FROM MAIN FUSE BOX, FUSE 1 (DIAGRAM 1 OF 10)
FUSE 1
FUSE 10
FUSE 11
FUSE 11 FUSE
FUSE 12
FUSE 13 FUSE 9
FUSE 14
FUSE 2
FUSE 3 FUSE 2
FUSE 4
FUSE 4 FUSE 7 TO LEFT FUSE BOX, FUSE 1 (DIAGRAM 8 OF 10)
FUSE 5
FUSE 7
FUSE 8
FUSE 9 FUSE 10
HIGH LEFT REAR DOOR CONTROL UNIT ON-BOARD COMPUTER NETWORK CONTROL UNIT
LEFT COCKPIT SUPPORT RELAY
LEFT FUSE BOX (LEFT SIDE OF DASH)
MAIN FUSE BOX (OVER VEHICLE ELECTRICAL SYSTEM BATTERY)
MAIN FUSE BOX (PRE-FUSE SOCKET) (OVER VEHICLE ELECTRICAL SYSTEM BATTERY)
MAIN FUSE BOX (REAR) (W/ PREPARATION STARTER BATTERY)
NCA WIRE
ON BOARD COMPUTER NETWORK CONTROL UNIT
ON-BOARD COMPUTER NETWORK CONTROL UNIT 3.2L 4.5L
POWER RELAY
PREPARATION STARTER BATTERY
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY 15 WITH DIAGNOSIS
RESIDUAL HEAT RELAY
STARTER GENERATOR
TERM 15 ACTUAT
TERM 15 DIAG
TERM 30
TERM 85
TERM 86
TERM 87
TO E-BOX, SH FUSE (DIAGRAM 8 OF 10)
TO FUSE 1 (DIAGRAM 9 OF 10) TO FUSE 1 (DIAGRAM 6 OF 10)
TO LEFT FUSE BOX, FUSE 14 (DIAGRAM 2 OF 10)
TO LEFT FUSE BOX, FUSE 2 (DIAGRAM 1 OF 10)
TO LEFT FUSE BOX, FUSE 47 (DIAGRAM 3 OF 10)
TRANSFER SOCKET
TYCO PARTITION ELEMENT
VEHICLE ELECTRICAL SYSTEM BATTERY
VIO WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 10) -> CURRENT RAIL S-FORM
Wiring diagram current rail s-form (2 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
BRN/VIO WIRE
CURRENT RAIL BATTERY WIRE
CURRENT RAIL L-FORM
CURRENT RAIL S-FORM
CURRENT RAIL STARTER WIRE
DRIVER IDENTIFICATION CONTROL UNIT
E-BOX
FUSE
FUSE 10
FUSE 7
GENERATOR
GRN/WHT WIRE
LOAD RELAY
MAIN FUSE BOX
MAIN FUSE BOX (PRE-FUSE SOCKET)
MAIN FUSE BOX (REAR)
MDI, DI RELAY
MOTOR CONTROL UNIT
NCA WIRE
ON BOARD COMPUTER NETWORK CONTROL UNIT
POWER RELAY
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
RED/YEL WIRE
S/H FUSE
STARTER
STARTER BATTERY
STARTER RELAY
TERM 30 BATT/START SIG BATT/START LOAD RELAY LOAD RELAY
TERM 50 DIAGNOSIS TERM 50 HS TERM 50 LS
TERM 50 IGN LOCK
TRANSFER SOCKET
TYCO PARTITION ELEMENT
VEHICLE ELECTRICAL SYSTEM BATTERY
Go to component -> Starting circuit -> CURRENT RAIL S-FORM
