Porsche Cayenne I (2002-2007) current rail battery wire current rail starter wire Wiring diagram
This page shows the only wiring diagram for the component.current rail battery wire current rail starter wire, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram current rail battery wire current rail starter wire (1 of 1)
+ DRIVER HEAD AIR BAG - DRIVER HEAD AIR BAG
+ PASSENGER SIDE AIR BAG - PASSENGER SIDE AIR BAG
AIR BAG
AIR BAG 1+ AIR BAG 1- AIR BAG 2- AIR BAG 2+
AIR BAG CONTROL UNIT (UNDER CENTER CONSOLE)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRASH
CURRENT RAIL BATTERY WIRE CURRENT RAIL STARTER WIRE
DIAGNOSIS
DRIVER IDENTIFICATION CONTROL UNIT
DRIVER'S HEAD AIR BAG (IN ROOF FRAME)
DRIVER'S SIDE AIR BAG (IN SEAT BACKREST SIDE ELEMENTS)
ESD
FUSE 26
GRN WIRE
GROUND
GROUND POINT
LEFT FUSE BOX (UNDER LEFT SIDE OF DASH)
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
PASSENGER'S SIDE AIR BAG
PASSENGER'S SIDE SIDE AIRBAG (IN SEAT BACKREST SIDE ELEMENTS)
PRE-FUSE SOCKET
STEERING COLUMN SWITCH MODULE
TERM 15
TERM 38
TERM 87
TYCO SWITCH PARTITION SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> CURRENT RAIL BATTERY WIRE CURRENT RAIL STARTER WIRE
