Porsche Cayenne I (2002-2007) circulation pump relay Wiring diagrams
This page contains all the electrical diagrams for the component. circulation pump relay, in which he is found in the car Porsche Cayenne I (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram circulation pump relay (1 of 3)
4.5L
4.5L TURBO
ACTUATION FAN 1
ACTUATION FAN 2
AFTER RUN COOLANT PUMP RELAY
BLK/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
CIRCULATION PUMP
CIRCULATION PUMP RELAY
COOLING FAN 1
COOLING FAN 2
COOLING WTR PMP
E-BOX
FRONT 2+2 OR LEFT/RIGHT CLIMATRONIC CONTROL UNIT
FUSE 1
FUSE 10
FUSE 12
FUSE 2
HOT AT ALL TIMES
HOT IN RUN AND START
LEFT FUSE BOX
MOTOR CONTROL UNIT
NCA WIRE
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RESIDUAL HEAT RELAY
STATIONARY HEATER
VIO/RED WIRE
WHT/RED WIRE
Go to component -> 4.5l, cooling fan circuit -> CIRCULATION PUMP RELAY
Wiring diagram circulation pump relay (2 of 3)
4.5L
4.5L TURBO
ACTUATION FAN 1
ACTUATION FAN 2
AFTER RUN COOLANT PUMP RELAY
BLK/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
CIRCULATION PUMP
CIRCULATION PUMP RELAY
COOLING FAN 1
COOLING FAN 2
COOLING WTR PMP
E-BOX
FRONT 2+2 OR LEFT/RIGHT CLIMATRONIC CONTROL UNIT
FUSE 1
FUSE 10
FUSE 12
FUSE 2
HOT AT ALL TIMES
HOT IN RUN AND START
LEFT FUSE BOX
MOTOR CONTROL UNIT
NCA WIRE
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RESIDUAL HEAT RELAY
STATIONARY HEATER
VIO/RED WIRE
WHT/RED WIRE
Go to component -> 4.5l turbo, cooling fan circuit -> CIRCULATION PUMP RELAY
Wiring diagram circulation pump relay (3 of 3)
3.2L
BACK-UP HORN
BRAKE FLUID SENSOR RESIDUAL HEAT RELAY
BRN WIRE
CIRCULATION PUMP RELAY
CLOSING AID RELAY
DRIVER IDENTIFICATION CONTROL UNIT
FRONT LEFT FOOTWELL LIGHT
FRONT LEFT INSTRUMENT PANEL OUTLET
FRONT MIDDLE COCKPIT CIGAR LIGHTER PLUG SOCKET
GATEWAY CONTROL UNIT LIGHT SWITCH
GRN WIRE
HAZARD WARNING SWITCH
HEADLIGHT CLEANER RELAY
INSTRUMENT CLUSTER
LEFT FRONT SEAT HEATER POTENTIOMETER
OIL LEVEL SENSOR
ON BOARD COMPUTER NETWORK CONTROL UNIT
PCM 2
PREPARATION BRAKE BOOSTER
PSM SWITCH
RIGHT FRONT SEAT HEATER POTENTIOMETER
SERVTRONIC RELAY
SIGNAL HORN
SPARE WHEEL RELEASE RELAY
STEERING COLUMN SWITCH MODULE
Go to component -> Ground distribution circuit (3 of 7) -> CIRCULATION PUMP RELAY
