Porsche Cayenne I (2002-2007) can high diag wiring diagram
This page shows the only wiring diagram for the component.can high diag, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
can high diag wiring diagram (1 of 1)
AIRBAG CONTROL UNIT
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CAN DRIVE HIGH CAN DRIVE LOW
CAN HIGH
CAN HIGH CAN LOW K LEAD
CAN HIGH DIAG
CAN HIGH PSM CAN LOW PSM
CAN LOW
CAN LOW CAN HIGH K LEAD
CAN LOW DIAG
CAN LOW LS CAN HIGH LS CAN LOW HS CAN HIGH HS
CAN-HIGH CAN-LOW
CAN-LOW CAN-HIGH
DIAG K CAN HIGH CAN LOW
DIAGNOSIS PLUG (UNDER STEERING COLUMN)
DRIVER IDENTIFICATION CONTROL UNIT
FUSE 39
FUSE 40
FUSE 51
FUSE 7
HOT AT ALL TIMES
HOT IN RUN AND START
K LEAD
LEFT FUSE BOX (UNDER LEFT SIDE OF DASH)
LEFT XENON HEADLIGHT
LEVEL CONTROL UNIT
MOTOR CONTROL UNIT
MULTIPLE SENSOR
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
PSM CONTROL UNIT
REAR COMFORT SYSTEM CONTROL UNIT
RED/YEL WIRE
RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH)
RIGHT XENON HEADLIGHT
TERM 15
TERM 30
TRAILER CONTROL UNIT
TRANSFER CASE CONTROL UNIT
TRANSMISSION CONTROL UNIT
Go to component -> Computer data lines circuit (1 of 2) -> CAN HIGH DIAG
