Porsche Cayenne I (2002-2007) backup horn Wiring diagrams
This page contains all the electrical diagrams for the component. backup horn, in which he is found in the car Porsche Cayenne I (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
backup horn wiring diagram (1 of 2)
BACKUP HORN
BACKUP LAMP ARDS ALARM SIREN CAN HIGH CAN LOW
BACKUP LIGHT
BACKUP LIGHT SW
BACKUP LIGHT SWITCH
BLK WIRE
BLK/BLU WIRE
BRN WIRE
CAN-HIGH CAN-LOW
COMPUTER DATA LINES SYSTEM
ENABLING
FUSE 21
FUSE 43
GEARBOX ASSEMBLY
HOT AT ALL TIMES
INSIDE MIRROR (ANTI-DAZZLING)
LEFT "D" PILLAR TAILLIGHT ASSEMBLY
LEFT BACKUP LIGHT
ON-BOARD COMPUTER NETWORK CONTROL UNIT (UNDER LEFT SIDE OF DASH)
ORG/BRN WIRE
ORG/GRN WIRE
REAR COMFORT SYSTEMS CONTROL UNIT (RIGHT REAR CARGO AREA)
RED/YEL WIRE
RIGHT "D" PILLAR TAILLIGHT ASSEMBLY
RIGHT BACKUP LIGHT
RIGHT FUSE BOX (UNDER RIGHT SIDE OF DASH)
SIG
SIGNAL TERM 30 TERM 31
TRANSMISSION CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT)
YEL/VIO WIRE
Go to component -> Back-up lamps circuit -> BACKUP HORN
backup horn wiring diagram (2 of 2)
BACKUP HORN
CLIMATRONIC CONTROL UNIT
CLOSING AID RELAY
COMPASS
FROM RIGHT FUSE BOX, FUSE 5 (DIAGRAM 4 OF 10)
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 27
FUSE 29
FUSE 30
FUSE 32 FUSE 31
FUSE 35 FUSE 34
FUSE 36
FUSE 56
FUSE 57
LEVEL CONTROL UNIT
ON-BOARD COMPUTER NETWORK CONTROL UNIT PASSENGER DOOR CONTROL UNIT
PASS- ENGER'S LUMBAR SWITCH
PASS- ENGER'S SEAT HEATER CONTROL UNIT
PASS- ENGER'S SEAT MEMORY
PASS- ENGER'S SEAT SWITCH MODULE
PSM CONTROL UNIT
REAR CLIMATRONIC CONTROL UNIT 2 + 2
REAR COMFORT SYSTEMS CONTROL UNIT HIGH RIGHT REAR DOOR CONTROL UNIT
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FUSE BOX (RIGHT SIDE OF DASH)
RIGHT REAR SEAT HEATER CONTROL UNIT
SPARE WHEEL RELEASE RELAY
TELEPHONE ROOF MODULE
TRANS- MISSION CONTROL UNIT SELECTOR LEVER SWITCH
TRANSFER CASE)
Go to component -> Power distribution circuit (5 of 10) -> BACKUP HORN
