Porsche Cayenne I (2002-2007) after-run water pump relay Wiring diagram
This page shows the only wiring diagram for the component.after-run water pump relay, which is found in the car Porsche Cayenne I (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram after-run water pump relay (1 of 1)
30 TERM
AFTER-RUN WATER PUMP RELAY
COOLING FAN 1
COOLING FAN 2
E-BOX (LEFT REAR OF ENGINE COMPT)
FROM TRANSFER SOCKET (DIAGRAM 1 OF 10)
FUEL INJECTOR 1
FUEL INJECTOR 2 FUEL INJECTOR 3
FUEL INJECTOR 4 IGNITION COIL 2
FUEL INJECTOR 5
FUEL INJECTOR 6
FUSE 1
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 7
FUSE 8
GRY/BLK WIRE
IGNITION COIL 1
IGNITION COIL 4 IGNITION COIL 6
IGNITION COIL 5 IGNITION COIL 3
LEFT FUEL PUMP RELAY
MAIN RELAY 1
MAIN RELAY 2
MOTOR CONTROL UNIT
MOTOR UNIT CONTROL
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FUEL PUMP RELAY
SECONDARY PUMP RELAY 1
STARTER RELAY
TERM 30
TERM 86
TO E-BOX, FUSE 11 (DIAGRAM 10 OF 10)
TO E-BOX, FUSE 9 (DIAGRAM 10 OF 10)
Go to component -> Power distribution circuit (9 of 10) -> AFTER-RUN WATER PUMP RELAY
