Porsche Cayenne Turbo III (2017-2023) Ground distribution circuit
Ground distribution circuit (1 of 6)
3.0L TURBO, 3.0L TURBO HYBRID
3.0L TURBO, 3.0L TURBO HYBRID 4.0L TURBO, 4.0L TURBO HYBRID
ADAPTIVE CRUISE CONTROL UNIT
AIR CONDITIONING SYSTEM PRESSURE SWITCH
BLU WIRE
BRN WIRE
BRN/BLU WIRE
CONNECTION (CONVENIENCE CAN BUS, LOW), IN REAR ARMREST WIRING HARNESS
CONNECTION (LF), IN COMMUNICATION WIRING HARNESS
CONNECTION 1, IN DRIVER SEAT BACKREST WIRING HARNESS
CONNECTION 2 (TELEPHONE), IN MAIN WIRING HARNESS
CONNECTION 2, IN WIRING HARNESS FOR ROOF OPERATION
CONNECTION 3, IN WIRING HARNESS FOR ROOF OPERATION
CONTINUED COOLANT CIRCULATION PUMP
COOLANT PUMP FOR HIGH- VOLTAGE BATTERY
COOLANT PUMP FOR LOW- TEMPERATURE CIRCUIT 2
ELECTRICAL AIR CONDITIONER COMPRESSOR
ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT
ENGINE/MOTOR CONTROL UNIT
FRONT LEFT HEADLIGHT
GEARBOX OIL COOLING PUMP
IGNITION COIL 1 (W/ OUTPUT STAGE)
IGNITION COIL 2 (W/ OUTPUT STAGE)
IGNITION COIL 3 (W/ OUTPUT STAGE)
IGNITION COIL 4 (W/ OUTPUT STAGE)
IGNITION COIL 5 (W/ OUTPUT STAGE)
IGNITION COIL 6 (W/ OUTPUT STAGE)
IGNITION COIL 7 (W/ OUTPUT STAGE)
IGNITION COIL 8 (W/ OUTPUT STAGE)
LEFT BONNET CONTACT SWITCH
LEFT CHARGE- AIR COOLER
LEFT FRONT RADAR SENSOR CONTROL UNIT FOR OBJECT DETECTION
RIGHT FRONT RADAR SENSOR CONTROL UNIT FOR OBJECT DETECTION
TREBLE HORN
TURBO CHARGER
Ground distribution circuit (2 of 6)
ALARM HORN
AUXILIARY HEATER CONTROL UNIT
AUXILIARY PUMP FOR HEATING
BASS HORN
BRAKE LIGHT SWITCH
BRAKE SERVO CONTROL UNIT
BRN WIRE
CIRCULATION PUMP 2
COOLANT PUMP
DIAGNOSTIC CONNECTION
DRIVER DOOR CONTROL UNIT
DRIVER SIDE CENTRAL LOCKING LOCK UNIT
ELECTRIC TRAILER BRAKES POTENTIOMETER
ELECTRICAL AIR CONDITIONER COMPRESSOR
ELECTRO-HYDRAULIC ENGINE MOUNTING CONTROL UNIT
HEADLIGHT WASHER SYSTEM PUMP
HIGH VOLTAGE BATTERY PRE- HEATING MIXING VALVE 2
HIGH-VOLTAGE HEATER (PTC)
LEFT FRONT EXTERIOR DOOR HANDLE CONTACT SENSOR
ONBOARD SUPPLY CONTROL UNIT
RADIATOR BLIND CONTROL MOTOR
RADIATOR BLIND CONTROL MOTOR 3
RADIATOR BLIND CONTROL MOTOR 5
RADIATOR FAN
REFRIGERANT CIRCULATION SOLENOID VALVE
RIGHT BONNET CONTACT SWITCH 2
RIGHT FRONT HEADLIGHT
RIGHT REAR TRIGGER 2 FOR PEDESTRIAN PROTECTION
SECONDARY AIR PUMP MOTOR
SIREN BACKUP HORN
SOLENOID FOR COOLANT CIRCUIT
SOLENOID VALVE 2
SOLENOID VALVE 3
SOLENOID VALVE 4
STRUCTURE-BORNE SOUND CONTROL UNIT
TERMINAL 15 VOLTAGE SUPPLY RELAY
THERMAL MANAGEMENT CONTROL UNIT
TRIGGER 1 FOR PEDESTRIAN PROTECTION
WINDSCREEN WIPER
Ground distribution circuit (3 of 6)
3.0L TURBO, 3.0L TURBO HYBRID
3.0L TURBO, 3.0L TURBO HYBRID 4.0L TURBO, 4.0L TURBO HYBRID
ADAPTIVE SUSPENSION CONTROL UNIT
ALL-WHEEL DRIVE CONTROL UNIT
ANTI-ROLL BAR CONTROL UNIT
AUTOMATIC GEARBOX CONTROL UNIT
BRAKE LIGHT SWITCH
BRN WIRE
CLUTCH ACTUATOR
CONNECTION 1, IN MAIN WIRING HARNESS
COOLANT PUMP FOR LOW- TEMPERATURE CIRCUIT 2
DRIVER ASSIST SYSTEMS CONTROL UNIT
EARTH CONNECTION, ON FUEL TANK FILLER NECK
ENGINE SOUND GENERATOR CONTROL UNIT 2
EXHAUST FLAP CONTROL UNIT
FRONT PASSENGER DOOR CONTROL UNIT
FRONT PASSENGER SIDE CENTRAL LOCKING LOCK UNIT
FRONT PASSENGER SIDE LIGHT FOR SILL PANEL MOULDING BACKGROUND LIGHTING
FUEL DELIVERY UNIT
FUEL PUMP CONTROL UNIT
GAS SUSPENSION COMPRESSOR
GEARBOX AUXILIARY HYDRAULIC PUMP
HEATED WINDSCREEM CONTROL UNIT
HIGH VOLTAGE BATTERY 1
MANUAL
POWER, CONTROL ELECTRONICS FOR ELECTRIC DRIVE
REFRIGERANT EXPANSION VALVE 2
RIGHT FRONT EXTERIOR DOOR HANDLE CONTACT SENSOR
RIGHT REAR SEAT HEATING CONTROL UNIT
WHT WIRE
Ground distribution circuit (4 of 6)
ADAPTIVE CRUISE CONTROL UNIT 3
BRN WIRE
CONNECTION 1 (INTERIOR MONITOR), IN FLOOR WIRING HARNESS
CONNECTION 2 (MIRROR MEMORY), IN FLOOR WIRING HARNESS
DATA BUS DIAGNOSTIC INTERFACE
DRIVER ASSIST SYSTEMS CONTROL UNIT
DRIVER SIDE AIR BAG IGNITER
DRIVER SIDE LIGHT SILL PANEL MOULDING BACKGROUND LIGHTING
DRIVER SIDE REAR LIGHT SILL PANEL MOULDING BACKGROUND LIGHTING
FRONT PASSENGER SIDE AIR BAG IGNITER
HEATED WINDSCREEM CONTROL UNIT
LEFT FRONT HEATED SEAT CUSHION
LEFT FRONT SEAT ADJUSTMENT CONTROL UNIT
LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT
LEFT FRONT SEAT BACKREST FAN 1
LEFT FRONT SEAT BELT
LEFT FRONT SEAT CUSHION FAN 1
LEFT FRONT SEAT EXTENSION HEATER ELEMENT
LEFT FRONT SEAT HEATED BACKREST
LEFT REAR CENTRAL LOCKING LOCK UNIT
LEFT REAR DOOR CONTROL UNIT
LEFT REAR EXTERIOR DOOR HANDLE CONTACT SENSOR
LEFT REAR SMART DISPLAY CONTROL UNIT
MANUAL
NIGHT VISION SYSTEM CONTROL UNIT
PASSENGER SIDE REAR LIGHT SILL PANEL MOULDING BACKGROUND LIGHTING
RIGHT FRONT HEATED SEAT CUSHION
RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT
RIGHT FRONT SEAT BACKREST FAN 1
RIGHT FRONT SEAT BELT
RIGHT FRONT SEAT CUSHION FAN 1
RIGHT FRONT SEAT EXTENSION HEATER ELEMENT
RIGHT FRONT SEAT HEATED BACKREST
RIGHT REAR SMART DISPLAY CONTROL UNIT
SEAT OCCUPIED RECOGNITION CONTROL UNIT
WHT WIRE
Ground distribution circuit (5 of 6)
ADJUSTABLE REAR SPOILER CONTROL UNIT
ADJUSTABLE REAR SPOILER MOTOR
AIR CONDITIONING SYSTEM CONTROL UNIT
ANTI-ROLL BAR CONTROL UNIT
ASHTRAY ILLUMINATION BULB
AUXILIARY HEATER REMOTE CONTROL RECEIVER
BLK WIRE
BLUETOOTH MOBILE PHONE COUPLING AERIAL
BRN WIRE
BRN/VIO WIRE
CENTER CONSOLE REAR STORAGE COMPARTMENT ILLUMINATION BULB
CIGARETTE LIGHTER
DIGITAL SOUND PACKAGE AMPLIFIER
DRIVER SIDE REAR AIR BAG IGNITER
ELECTROMECHANICAL PARKING BRAKE BUTTON
HIGH VOLTAGE BATTERY CHARGING UNIT 1
LEFT DRINKS HOLDER ILLUMINATION BULB
MOBILE TELEPHONE AERIAL AMPLIFIER
PASSENGER SIDE REAR AIR BAG IGNITER
RADIO CONTROLLED PARKING CONTROL UNIT
REAR AIR CONDITIONING SYSTEM OPERATING, DISPLAY UNIT
REAR CENTER ASHTRAY ILLUMINATION BULB
REAR FRESH AIR BLOWER
RIGHT LUGGAGE COMPARTMENT LIGHT
RIGHT TAIL LIGHT CLUSTER
SELECTOR LEVER SENSORS CONTROL UNIT
STORAGE COMPARTMENT ILLUMINATION SWITCH
TANK FILLER FLAP LOCKING MOTOR
USB CHARGING SOCKET 1
VEHICLE LOCATION SYSTEM AERIAL 3 SHIELD
VEHICLE LOCATION SYSTEM CONTROL UNIT SHIELD
Ground distribution circuit (6 of 6)
3.0L TURBO, 3.0L TURBO HYBRID
AIR HUMIDITY RAIN, LIGHT SENSOR
ANTI-ROLL BAR CONTROL UNIT 2
AXLE DIFFERENTIAL LOCK CONTROL UNIT
BRN WIRE
CLIMATRONIC OPERATING UNIT WIRING HARNESS
CLIMATRONIC WIRING HARNESS, RADIATOR FAN
CONNECTON 1, IN ABS WIRING HARNESS
DVD CHANGER
ENGINE SOUND GENERATOR CONTROL UNIT
EXHAUST FLAP CONTROL UNIT
EXHAUST FLAP CONTROL UNIT 2
FRONT ROOF MODULE
GARAGE DOOR OPERATION CONTROL UNIT
HEATED REAR WINDOW RELAY
HIGH VOLTAGE BATTERY CHARGING UNIT 1
INTERIOR MIRROR
LANE CHANGE ASSIST CONTROL UNIT
LANE CHANGE ASSIST CONTROL UNIT 2
LEFT LUGGAGE COMPARTMENT LIGHT
LEFT REAR BRAKE PAD WEAR SENDER
LEFT REAR SEAT HEATING CONTROL
LEFT TAIL LIGHT CLUSTER
ONBOARD SUPPLY CONTROL UNIT 2
REAR LID POWER OPENING SENDER
RELAY CARRIER 6
SEAT VENTILATION RELAY
SLIDING SUNROOF ADJUSTMENT CONTROL UNIT
SUBWOOFER LOADSPACE FLOOR
TIRE PRESSURE MONITORING SYSTEM CONTROL UNIT
TRAILER DETECTOR CONTROL UNIT
VEHICLE LOCATION SYSTEM CONTROL UNIT
VIO/BRN WIRE
WHT WIRE
YEL WIRE
