Porsche Cayenne Turbo III (2017-2023) water pump ls Wiring diagrams

ACTIVATED CHARCOAL FILTER SOLENOID VALVE 1 ACTIVATED CHARCOAL FILTER SOLENOID VALVE 2 AFTER-RUN COOLANT PUMP BLK/GRN WIRE BLK/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE CAMSHAFT ADJUSTER CYL 2 CAMSHAFT ADJUSTER CYL 3 CAMSHAFT ADJUSTER CYL 5 CAMSHAFT ADJUSTER CYL 8 CONTINUED COOLANT CIRCULATION PUMP ENGINE/MOTOR CONTROL UNIT FUEL LOW PRESS SENS + FUEL LOW PRESS SENS GND FUSE BOXES GRN/BLU WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND GRY/BRN WIRE INLET CAM ACTUATOR 1 CYLINDER 2 INLET CAM ACTUATOR 1 CYLINDER 3 INLET CAM ACTUATOR 1 CYLINDER 5 INLET CAM ACTUATOR 1 CYLINDER 8 LARGE LIFT MAP-CONTROLLED ENGINE COOLING SYSTEM THERMOSTAT MECHANICAL COOLANT PUMP SWITCH VALVE OIL LEVEL/ OIL TEMP SENS + OIL LEVEL/OIL TEMP SENS OIL PRESS REGULATING VLV HS OIL PRESS REGULATING VLV LS OIL PRESS SENS OIL PRESS SW OIL PRESSURE CONTROL VALVE OIL PRESSURE SWITCH POSITIVE RED/BLU WIRE RED/BRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE SIG SIGNAL SMALL LIFT TANK VENT VLV 1 TANK VENT VLV 2 TERM 87 THERMOSTAT MAP VALVE VIO/RED WIRE VIO/YEL WIRE WATER PUMP HS WATER PUMP LS WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

ACTIVATED CHARCOAL FILTER SOLENOID VALVE 1 ACTIVATED CHARCOAL FILTER SOLENOID VALVE 2 AFTER-RUN COOLANT PUMP BLK/GRN WIRE BLK/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE CAMSHAFT ADJUSTER CYL 2 CAMSHAFT ADJUSTER CYL 3 CAMSHAFT ADJUSTER CYL 5 CAMSHAFT ADJUSTER CYL 8 CONTINUED COOLANT CIRCULATION PUMP ENGINE/MOTOR CONTROL UNIT FUEL LOW PRESS SENS + FUEL LOW PRESS SENS GND FUSE BOXES GRN/BLU WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND GRY/BRN WIRE INLET CAM ACTUATOR 1 CYLINDER 2 INLET CAM ACTUATOR 1 CYLINDER 3 INLET CAM ACTUATOR 1 CYLINDER 5 INLET CAM ACTUATOR 1 CYLINDER 8 LARGE LIFT MAP-CONTROLLED ENGINE COOLING SYSTEM THERMOSTAT MECHANICAL COOLANT PUMP SWITCH VALVE OIL LEVEL/ OIL TEMP SENS + OIL LEVEL/OIL TEMP SENS OIL PRESS REGULATING VLV HS OIL PRESS REGULATING VLV LS OIL PRESS SENS OIL PRESS SW OIL PRESSURE CONTROL VALVE OIL PRESSURE SWITCH POSITIVE RED/BLU WIRE RED/BRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE SIG SIGNAL SMALL LIFT TANK VENT VLV 1 TANK VENT VLV 2 TERM 87 THERMOSTAT MAP VALVE VIO/RED WIRE VIO/YEL WIRE WATER PUMP HS WATER PUMP LS WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
