Porsche Cayenne Turbo III (2017-2023) vehicle location system aerial 3 Wiring diagram
This page shows the only wiring diagram for the component.vehicle location system aerial 3, which is found in the car Porsche Cayenne Turbo III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vehicle location system aerial 3 (1 of 1)
ANTENNA
BLK WIRE
BRN WIRE
CAN COMFORT HIGH
CAN COMFORT LOW
COMPUTER DATA LINES SYSTEM
DRIVER CARD ANTENNA
FUSE 10
FUSE HOLDER J
GPS SIGNAL
GRN WIRE
GSM SIGNAL
HOT AT ALL TIMES
N/A
NCA WIRE
ONBOARD SUPPLY CONTROL UNIT 2
ORG/BRN WIRE
REAR FUSE BOX
SHIELD
SIGNAL
TELEPHONE
TERM 15
TERM 30
TERM 31
VEHICLE LOCATION SYSTEM AERIAL 1
VEHICLE LOCATION SYSTEM AERIAL 2
VEHICLE LOCATION SYSTEM AERIAL 3
VEHICLE LOCATION SYSTEM CONTROL UNIT
WHT WIRE
Go to component -> Vehicle positioning system circuit -> VEHICLE LOCATION SYSTEM AERIAL 3
