Porsche Cayenne Turbo III (2017-2023) vehicle control unit location system Wiring diagram
This page shows the only wiring diagram for the component.vehicle control unit location system, which is found in the car Porsche Cayenne Turbo III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vehicle control unit location system (1 of 1)
ANTI-ROLL BAR CONTROL UNIT
ANTI-ROLL BAR CONTROL UNIT 2
BLK/WHT WIRE
BLUETOOTH MOBILE PHONE COUPLING AERIAL
BLUETOOTH TRANSCEIVER RADIO- CONTROLLED PARKING
DRIVER ASSIST SYSTEMS CONTROL UNIT
DVD CHANGER
FROM FUSE CARRIER 9 (DIAGRAM 7 OF 9)
FUEL TANK LEAK DETECTION CONTROL UNIT
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE HOLDER J
GARAGE DOOR OPERATION CONTROL UNIT
LANE CHANGE ASSIST CONTROL UNIT
LANE CHANGE ASSIST CONTROL UNIT 2
MOBILE TELEPHONE AERIAL AMPLIFIER
N/A
ONBOARD SUPPLY CONTROL UNIT 2
REAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
REVERSING CAMERA SYSTEM CONTROL UNIT
RIGHT FRONT EXTERNAL AUDIO SOURCES
SUBWOOFER
TERMINAL 40 WIRING JUNCTION BOX
TIRE PRESSURE MONITORING SYSTEM CONTROL UNIT
VEHICLE CONTROL UNIT LOCATION SYSTEM
VIO WIRE
WHT WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Power distribution circuit (8 of 9) -> VEHICLE CONTROL UNIT LOCATION SYSTEM
