Porsche Cayenne Turbo III (2017-2023) term 30 left Wiring diagram
This page shows the only wiring diagram for the component.term 30 left, which is found in the car Porsche Cayenne Turbo III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram term 30 left (1 of 1)
BRN WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
FLEXRAY 2+ INPUT
FLEXRAY 2- OUTPUT
FLEXRAY 2- OUTPUT FLEXRAY 2- INPUT
FUSE 4
FUSE HOLDER J
GRN WIRE
HOT AT ALL TIMES
LANE CHANGE ASSIST CONTROL UNIT
LANE CHANGE ASSIST CONTROL UNIT 2
N/A
ORG/ WIRE
ORG/BRN WIRE
PNK FLEXRAY 2+ OUTPUT PNK FLEXRAY 2+ INPUT WIRE
REAR FUSE BOX
RED/GRN WIRE
TERM 30 LEFT
TERM 30 RIGHT PNK FLEXRAY 2+ OUTPUT PNK FLEXRAY 2+ INPUT WIRE
Go to component -> Lane change assistance circuit -> TERM 30 LEFT
