Porsche Cayenne Turbo III (2017-2023) seat cushion bolster adj Wiring diagrams

BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CAN HIGH CAN LOW CODING PIN (DS-PS) COMPUTER DATA LINES SYSTEM DRIVER MULTI-CONTOUR SEAT CONTROL UNIT DRIVER SEAT MULTI-CONTOUR COMPRESSOR FRONT FUSE BOX FUSE HOLDER S GRN WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES LEFT FRONT MASSAGE SEAT CONTROL UNIT LEFT FRONT SEAT ADJUSTMENT CONTROL UNIT LEFT FRONT SEAT ADJUSTMENT OPERATING UNIT LEFT SEAT ADJUSTMENT CIRCUIT BREAKER LIN 2 LNV TEASTER LUMBAR FORWARD/BACK LUMBAR HIGH LOW MASSAGE ORG/BRN WIRE PUMP RED/BLK WIRE RED/BLU WIRE SEAT BACKREST BOLSTER ADJ SEAT CUSHION BOLSTER ADJ SEAT CUSHION DEPTH ADJ SHV TEASTER SLV TEASTER SNV TEASTER STV TEASTER SUPPLY TERM 30 TERM 30 S TERM 30 SWITCHED TERM 31 VIO/BLU WIRE WHT WIRE WHT/GRY WIRE WHT/RED WIRE YEL/BLK WIRE YEL/GRN WIRE

BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CAN HIGH CAN LOW CODING PIN (DS-PS) COMPUTER DATA LINES SYSTEM FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL UNIT FRONT PASSENGER SEAT MULTI-CONTOUR COMPRESSOR FUSE HOLDER Z GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE HOT AT ALL TIMES LIN 2 LNV TEASTER LUMBAR FORWARD/BACK LUMBAR HIGH LOW MASSAGE ORG/BRN WIRE PUMP REAR FUSE BOX RED/BLK WIRE RED/BLU WIRE RIGHT FRONT MASSAGE SEAT CONTROL UNIT RIGHT FRONT SEAT ADJUSTMENT CONTROL UNIT RIGHT FRONT SEAT ADJUSTMENT OPERATING UNIT RIGHT SEAT ADJUSTMENT CIRCUIT BREAKER SEAT BACKREST BOLSTER ADJ SEAT CUSHION BOLSTER ADJ SEAT CUSHION DEPTH ADJ SHV TEASTER SLV TEASTER SNV TEASTER STV TEASTER SUPPLY TERM 30 TERM 30 S TERM 30 SWITCHED TERM 31 VIO/BLU WIRE WHT WIRE WHT/GRY WIRE WHT/RED WIRE YEL/BLK WIRE YEL/GRN WIRE
