Porsche Cayenne Turbo III (2017-2023) high rail fuel pressure sender Wiring diagrams

This page contains all the electrical diagrams for the component. high rail fuel pressure sender, in which he is found in the car Porsche Cayenne Turbo III (2017-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram high rail fuel pressure sender (1 of 3)

Wiring diagram high rail fuel pressure sender for Porsche Cayenne Turbo III (2017-2023) (1 of 3)

Get access

BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/VIO WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE CHARGE PRESSURE SENDER EXHAUST CAMSHAFT CONTROL VALVE 1 EXHAUST CAMSHAFT CONTROL VALVE 2 FULLY VARIABLE OIL PUMP GRN/YEL WIRE GROUND GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/YEL WIRE HIGH RAIL FUEL PRESSURE SENDER INLET CAM ACTUATOR 1 CYLINDER 1 INLET CAM ACTUATOR 1 CYLINDER 2 INTAKE AVS INTAKE CAMSHAFT CONTROL VALVE 1 INTAKE CAMSHAFT CONTROL VALVE 2 INTAKE MANIFOLD PRESSURE SENDER KNOCK SENSOR #2 KNOCK SENSOR 1 LOW FUEL PRESSURE SENDER NEG POS RED/BLK WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SENT SIGNAL SIG SIG (1) SIG (2) SPPLY TANK BREATHER PRESSURE SENSOR 1 TERM 31 TERM 87 UNIT CYL 2 VIO WIRE VIO/BLU WIRE VIO/GRN WIRE WHT WIRE WHT/GRN WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/RED WIRE

Go to component -> Wiring diagram engine performance 2.9l turbo (2 of 8) -> HIGH RAIL FUEL PRESSURE SENDER

Wiring diagram high rail fuel pressure sender (2 of 3)

Wiring diagram high rail fuel pressure sender for Porsche Cayenne Turbo III (2017-2023) (2 of 3)

Get access

BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/VIO WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE EXHAUST CAMSHAFT CONTROL VALVE 1 EXHAUST CAMSHAFT CONTROL VALVE 2 FULLY VARIABLE OIL PUMP GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/YEL WIRE HIGH RAIL FUEL PRESSURE SENDER INLET CAM ACTUATOR 1 CYLINDER 1 INLET CAM ACTUATOR 1 CYLINDER 2 INTAKE AVS INTAKE CAMSHAFT CONTROL VALVE 1 INTAKE CAMSHAFT CONTROL VALVE 2 INTAKE MANIFOLD PRESSURE SENDER KNOCK SENSOR #2 KNOCK SENSOR 1 LOW FUEL PRESSURE SENDER NEG POS RED/BLK WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SIG SIG (1) SIG (2) SPPLY TANK BREATHER PRESSURE SENSOR 1 TERM 31 TERM 87 UNIT CYL 2 VIO WIRE VIO/BLU WIRE VIO/GRN WIRE WHT WIRE WHT/GRN WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/RED WIRE

Go to component -> Wiring diagram engine performance 3.0l turbo, engine controls circuit (2 of 8) -> HIGH RAIL FUEL PRESSURE SENDER
