Porsche Cayenne Turbo III (2017-2023) gnd sensors Wiring diagram
This page shows the only wiring diagram for the component.gnd sensors, which is found in the car Porsche Cayenne Turbo III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd sensors (1 of 1)
ACTUATORS/SENS SPLY
AXLE DIFFERENTIAL LOCK CONTROL UNIT
AXLE DIFFERENTIAL LOCK MOTOR
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
ENG TEMP
ENG TEMP GND
ENGINE BRAKE A
ENGINE BRAKE B
ENGINE TEMP
FLEXRAY BRANCH 1 BM
FLEXRAY BRANCH 1 BP
FLEXRAY BRANCH 2 BM
FLEXRAY BRANCH 2 BP
FUSE 10
FUSE HOLDER D
FUSE HOLDER H
GND SENSORS
GRN WIRE
GRN/BLK WIRE
GRY/WHT WIRE
HALL SIGNAL 1
HALL SIGNAL 3
HOT AT ALL TIMES
HOT W/ TERMINAL 15 VOLTAGE SUPPLY RELAY ENERGIZED
MAGNETIC BRAKE HIGH
MAGNETIC BRAKE LOW
MOTOR
MTR A
MTR B
N/A
PNK WIRE
POS SIG 1
POS SIG 2
REAR FUSE BOX
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
SENS GND
TERM 15
TERM 30
TERM 31
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Rear differential lock circuit -> GND SENSORS
