Porsche Cayenne Turbo III (2017-2023) fun ind Wiring diagram
This page shows the only wiring diagram for the component.fun ind, which is found in the car Porsche Cayenne Turbo III (2017-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fun ind (1 of 1)
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
ELECTRONIC STABILIZATION PROGRAM CONTROL UNIT
FLEXRAY 1- INPUT
FRONT FUSE BOX
FUN IND
FUSE 11
FUSE 6
FUSE HOLDER E
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT PARKING BRAKE MOTOR
LH EPB ACT +
LH EPB MTR +
MOTOR
N/A
PNK FLEXRAY 1+ OUTPUT WIRE
PRK BRK FUN DISPLAY
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RH EPB ACT +
RH EPB MTR -
RIGHT PARKING BRAKE MOTOR
SENSOR
SWITCH 1
SWITCH 2
SWITCH 3
SWITCH 4
TERM 30
TERM 31
TERM 31 VALVES
Go to component -> Electronic parking brake circuit -> FUN IND
